SANY SR400R - Electric Cabinet

3-86
Safety, Operation and Maintenance Manual-September 30, 2019
3.17 Electric Cabinet
Fig.3-81 Electric Cabinet
1. Controller 2. ECM relay 3. Fuel pump relay 4. Start-up/shut-down
relay
5. Integrated box 6. Start relay 7. Barometric
pressure sensor
8. Preheat relay
9. Charge lamp 10. Diagnostic
indicator
11. Preheat indicator 12. Fuse
1
2
3
4
5
6
7
8
12
9
10
11
System Function SR400R Rotary Drilling Rig
