- 4 -
PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT
ARE DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE
MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
1 614 326 2077 CARTON CASE
2 614 319 7430 CUSHION,REAR
3 614 319 7447 CUSHION,FRONT
4 614 326 2190 INSTRUCTION MANUAL
5 645 047 0509 POLY SHEET-0900X0300*NC
6 645 005 1227 ASSY,ANTENA,LOOP
or 645 046 8322 ASSY,ANTENA,LOOP
7 614 318 9404 LID,BATTERY,SERVICE
8 645 057 4696 REMOCON,RB-DA2000
9 614 325 7868 ASSY,BOX,SPEAKER(L,R)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 325 7981 COVER,DECK
2 614 326 3043 DEC,WINDOW,DECK
3 614 320 3520 SPRING,WIRE,DOOR DECK
4 614 319 7096 LID,CASSETTE
5 614 323 2230 PANEL
6 614 325 7967 ASSY,PANEL,FRONT
7 614 319 7072 KNOB,VOLUME
8 614 326 3050 DEC,WINDOW,LCD
9 614 309 7969 ASSY,GEAR,LID,CASSETTE
10 614 303 1277 LATCH,CAM,DECK,DOOR,LOCKING
11 614 323 2162 BUTTON,OPERATION,11 KEYS
12 614 319 6945 BUTTON,RIGHT,4 KEYS
13 614 325 7974 BUTTON,POWER
14 614 325 8025 REFLECTOR,STANDBY,LED
15 614 310 3899 SPACER,MECHA,MTG CD+DA11
16 614 307 2072 COVER,PICK-UP
17 614 319 7119 MOUNTING,CD
18 614 322 2125 ASSY,GEAR,LID CD
19 614 303 0263 LATCH,PUSH,CD DOOR LOCKING
20 614 319 7201 SPRING,WIRE,DOOR CD
21 614 307 8821 PULLEY
22 614 303 0256 LATCH,MAGNET
23 614 319 7102 LID,CD
24 614 325 8230 DEC,WINDOW,CD
25 614 304 5700 HOLDER,MAIN PCB
26 614 319 8741 BUTTON,POWER
27 614 316 1172 STOPPER
28 614 326 1667 ASSY,CABINET,REAR
29 614 325 6014 ASSY,MECHA,DA11T3CN-SASH
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 156 2105 SCR S-TPG BIN 2.3X6,
PANEL+PANEL FRONT
Y02 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+LATCH,CAM
Y03 411 021 3503 SCR S-TPG BIN 3X10,
F-PANEL+DECK MECHA
Y04 614 129 9136 LUG,LEAD FIX
Y05 411 020 8905 SCR S-TPG BRZ+FLG 3X10,
F-PANEL+ASSY.GEAR,DECK
Y06 411 021 3503 SCR S-TPG BIN 3X10,
SWITCH,PWB+MTG CD
Y07 411 021 1806 SCR S-TPG BIN 2.6X10,
MTG CD+DA11
Y08 411 092 0906 WASHER Z 2.6X10X0.5,
MTG CD+DA11
Y09 411 020 8905 SCR S-TPG BRZ+FLG 3X10,
F-PANEL+ASSY.GEAR,CD
Y10 411 021 4906 SCR S-TPG BIN 3X20,
F-PANEL+MOUNTING,CD
Y11 411 021 3503 SCR S-TPG BIN 3X10,
MAIN PCB+MTG CD
Y12 411 184 0906 SCR S-TPG BIN 2.3X10,
LID CD+DEC WINDOW CD
Y13 412 032 6408 SPECIAL SCREW,REAR+P-TRANS
Y14 411 021 6405 SCR S-TPG BIN 3X8,
REAR+SW1 PCB,
REAR+HOLDER
Y15 411 021 3503 SCR S-TPG BIN 3X10,
REAR+STOPPER
Y16 411 098 7800 SCR S-TPG FLT 3X12,
REAR+MTG(L/R)
Y17 411 021 4906 SCR S-TPG BIN 3X20,
REAR+PANEL,FRONT
Y18 411 021 3503 SCR S-TPG BIN 3X10,
REAR+ANT TERMINAL,
REAR+AUDIO TERMINAL
Y19 411 021 3503 SCR S-TPG BIN 3X10,
REAR+MTG CD
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 322 2279 ASSY,WIRE,AMP-TAPE MECHA
52 614 326 3760 FLEXIBLE FLAT CABLE,
FRONT-AMP
or 614 327 0874 FLEXIBLE FLAT CABLE,
FRONT-AMP
53 614 326 2794 FLEXIBLE FLAT CABLE,
CD-CD MECHA
or 614 327 0836 FLEXIBLE FLAT CABLE,
CD-CD MECHA
54 614 316 8041 ASSY,WIRE,CD-CD MECHA
55 614 274 2013 CORD,ID CONNECTOR,FM ANT
56 423 016 7908 FUSE 250V 2.5A
57 645 051 8744 TRANS,POWER
58 645 032 1887 CORD,POWER-2.0MK
