- 5 -

PARTS LIST

REF.NO. PART NO. DESCRIPTIONFRONT P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

71 614 325 7219 ASSY,PWB,FRONT (Only Initial)

AC601 614 320 3469 COVER,LED

AH601 614 320 3483 HOLDER,LCD

AS601 614 314 9286 DEC,SHEET,LCD

CN601 645 009 8482 SOCKET,FFC 28P

or 645 012 5324 SOCKET,FPC 28P

D6010 407 012 4406 DIODE 1SS133

D6110 407 012 4406 DIODE 1SS133

D6111 407 012 4406 DIODE 1SS133

D6112 407 225 7300 LED LT03B3-43-URE1

D6113 407 012 4406 DIODE 1SS133

D6301 408 049 3905 LED SLP-9G118C-51HS-T1,

STAND-BY-LED

IC601 410 469 0709 IC LC867232A-51D2

L6010 645 001 5441 INDUCTOR,2.2U K

LCD60 645 050 7397 LCD

Q6107 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

or 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

Q6108 405 017 9709 TR 2SC3330-U

or 405 017 9600 TR 2SC3330-T

or 405 011 8609 TR 2SC1740S-S

or 405 011 8500 TR 2SC1740S-R

or 405 143 8706 TR KTC3199-GR

Q6301 405 146 1209 TR KRC104M

or 405 000 6104 TR DTC144ES

Q6302 405 000 6104 TR DTC144ES

or 405 146 1209 TR KRC104M

S6001 645 054 1230 SWITCH,ROTARY(ENCODER)

S6110 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6111 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6112 614 220 5471 SWITCH,TACT

or 614 240 1002 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

S6113 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6114 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6115 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6116 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6117 614 240 1002 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

or 614 220 5471 SWITCH,TACT

S6210 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6211 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6212 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6213 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

or 645 006 5958 SWITCH,PUSH 1P-1T

S6214 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6215 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6216 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

S6217 645 006 5958 SWITCH,PUSH 1P-1T

or 614 240 1002 SWITCH,TACT

or 614 220 5471 SWITCH,TACT

SE601 407 217 1101 PHOTO DIODE SPS-442-1G

X6102 645 018 6103 OSC,CERAMIC 6.000MHZ

or 645 057 1138 OSC,CERAMIC 6.0MHZ

CD P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 325 7202 ASSY,PWB,CD (Only Initial)

CN111 645 059 0498 SOCKET,FPC 16P

or 645 026 2470 SOCKET,FFC 16P

or 645 033 8168 SOCKET,FPC 16P

CN113 614 310 2472 PLUG,6P

or 645 005 8127 PLUG,6P

D1402 407 099 5204 ZENER DIODE MTZJ5.1B

D1403 407 012 4406 DIODE 1SS133

D1404 407 012 4406 DIODE 1SS133

D1405 407 012 4406 DIODE 1SS133

D1410 407 098 3300 DIODE RL153-BF-S2

D1482 407 012 4406 DIODE 1SS133

IC101 409 503 5701 IC LA9242M-MPB

IC102 409 539 9704 IC LC78629E

IC103 409 486 8706 IC MM1469XH

L1451 645 001 4550 INDUCTOR,10U K

PR140 645 014 2499 PROTECTOR,0.4A 125V

Q1301 405 008 7301 TR 2SB810-F

or 405 008 7202 TR 2SB810-E

or 405 008 6809 TR 2SB808-F-SPA

Q1401 405 009 5306 TR 2SB927-T

or 405 009 5207 TR 2SB927-S

or 405 141 3604 TR KTA1273-Y

X1451 614 231 2667 RESONATOR

or 645 057 1145 OSC,CERAMIC 16.93MHZ

AMPLIFIER & TUNER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

73 614 326 8109 ASSY,PWB,AMP-TU (Only Initial)

C2457 403 259 0508 NP-ELECT 1U M 50V

C4601 403 057 3503 POLYESTER 0.1U K 50V

C4605 403 061 3605 POLYESTER 0.039U J 50V

C4606 403 061 7702 POLYESTER 4700P J 50V

C4607 403 059 3204 POLYESTER 2200P J 50V

C4608 403 060 2807 POLYESTER 0.027U K 50V

C4734 403 058 4608 POLYESTER 0.15U J 50V

C4834 403 058 4608 POLYESTER 0.15U J 50V

C4913 403 329 5907 ELECT 3300U M 25V

CN201 614 221 8273 TERMINAL

CN202 645 038 7715 TERMINAL

or 645 025 4703 TERMINAL,ANTENNA

CN400 645 009 8482 SOCKET,FFC 28P

or 645 012 5324 SOCKET,FPC 28P

CN401 645 006 1875 PLUG,2P,SPEAKER

CN402 645 006 1875 PLUG,2P,SPEAKER

CN440 614 310 2472 PLUG,6P

or 645 005 8127 PLUG,6P

CN441 614 310 2731 PLUG,2P,POWER

or 645 004 2881 PLUG,2P,POWER

CN442 614 276 6835 SOCKET,JACK

CN443 645 011 6384 JACK,PHONE D3.6,HEADPHONE

CN445 614 310 2519 PLUG,10P

or 645 005 8158 PLUG,10P

CT252 645 032 5663 TRIMMER,7PF

D2101 407 157 8109 VARACTOR DI SVC211-B

D2102 407 157 8109 VARACTOR DI SVC211-B

D2103 407 012 4406 DIODE 1SS133

D2151 407 012 4406 DIODE 1SS133

Other manuals for Sanyo DC-DA2000

Instruction Manual8 pages

Questions and Answers:

Need help?

Do you have a question about the Sanyo DC-DA2000 and is the answer not in the manual?

Sanyo DC-DA2000 Specifications

Tuner

FM frequency range	87.5 - 108 MHz
AM frequency range (9 kHz step)	522 - 1710 kHz
AM frequency range (10 kHz step)	520 - 1710 kHz

CD Player

Channels	2-channel stereo
Sampling frequency	44.1 kHz
Laser output	0.6 mW
Wave length	790 nm

Cassette Deck

Track system	4-track, 2-channel stereo
Frequency response	80 Hz to 15 kHz
Signal-to-noise ratio	40 dB
Wow/flutter	0.15% (WRMS)
Fast forward/rewind time	Approx. 110 sec. (C-60)

General

Output power	4W x 2
Power requirements	AC 230 ~ 240 V, 50 Hz
Power consumption	21 W
Dimensions	150(W) x 230(H) x 205(D) mm
Weight	2.3 kg

Speaker Systems

Type	Full range bass reflex
Unit used	10 cm cone type
Maximum power-handling capacity	8 W (peak)
Nominal impedance	4 ohms
Dimensions	145(W) x 230(H) x 170(D) mm
Weight	1.2 kg (per speaker)
