- 6 -

Q4801 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4851 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

or 405 021 0600 TR 2SD1012-G-SPA

or 405 021 0204 TR 2SD1012-F-SPA

or 405 151 4400 TR KTD1303

Q4930 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4931 405 000 0508 TR DTA114ES

or 405 110 5400 TR KRA102M-A

Q4951 405 138 6403 TR KTD2058Y

or 405 095 1602 TR 2SD2061-E

or 405 095 1701 TR 2SD2061-F

Q4960 405 155 0002 TR MPSA56

Q4961 405 155 0002 TR MPSA56

Q4962 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4963 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4992 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

Q4993 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4995 405 141 3703 TR KTA1271-Y

or 405 008 2405 TR 2SB698-F

or 405 008 2504 TR 2SB698-G

R4940 402 081 0205 FUSIBLE RES 27 JA 1/4W

S2001 645 023 5795 SWITCH,LEVER

SA401 411 021 6405 SCR S-TPG BIN 3X8

SA402 411 021 6405 SCR S-TPG BIN 3X8

T2002 645 046 2023 FILTER,450KHZ

or 645 060 4072 FILTER,450KHZ

X2451 645 023 4965 OSC,CRYSTAL 7.2MHZ

XF211 645 059 0047 FILTER,BP

or 645 026 2975 FILTER,BP 108MHZ

or 614 252 1045 FILTER,LC

XF221 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF222 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF231 645 059 0054 CERAMIC FILTER 450KHZ

or 645 041 9324 CERAMIC FILTER 450KHZ

XF233 645 040 9981 TRANS,IF 10.7MHZ

or 645 039 9923 TRANS,IF 10.7MHZ

or 645 060 4089 TRANS,IF 10.7MHZ

PARTS LIST

REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

D2153 407 105 1602 VARACTOR DI SVC342M-V

or 407 105 1305 VARACTOR DI SVC342L-V

D2451 407 012 4406 DIODE 1SS133

D2452 407 153 7502 ZENER DIODE GZS3.0B

D2453 407 012 4406 DIODE 1SS133

D2456 407 012 4406 DIODE 1SS133

D2466 407 012 4406 DIODE 1SS133

D4951 407 099 6102 ZENER DIODE MTZJ10B

D4953 407 012 4406 DIODE 1SS133

D4954 407 012 4406 DIODE 1SS133

D4960 407 012 4406 DIODE 1SS133

D4961 407 012 4406 DIODE 1SS133

D4993 407 012 4406 DIODE 1SS133

HS401 614 319 7065 HEAT SINK

IC211 409 016 0200 IC LA1186N-AUDIO

IC231 409 474 3201 IC LA1844ML

IC241 409 439 4502 IC LC72121M-D

IC440 409 451 7406 IC AN7348K

IC441 409 474 6103 IC LC75342M

IC442 409 295 7402 IC TA8229K

IC443 409 189 3404 IC BA7755A

IC446 409 039 9204 IC NJM78L05A

L2102 645 040 2753 INDUCTOR,AIR —

L2103 645 040 2746 COIL,AIR —

L2104 645 002 1534 INDUCTOR,8.2U K

L2151 645 037 2377 TRANS,ANT,796KHZ

L2153 645 040 2739 TRANS,OSC,796KHZ

L2451 645 031 7842 INDUCTOR,100U K

or 645 001 4581 INDUCTOR,100U K

L4600 645 006 1523 INDUCTOR,470U J

L4601 645 006 1523 INDUCTOR,470U J

L4602 645 037 2858 CORE,PIPE

L4603 645 006 1523 INDUCTOR,470U J

L4604 645 037 2858 CORE,PIPE

L4781 645 002 1459 INDUCTOR,22U K

L4782 645 002 1459 INDUCTOR,22U K

L4881 645 002 1459 INDUCTOR,22U K

L4882 645 002 1459 INDUCTOR,22U K

L4981 645 002 1459 INDUCTOR,22U K

PR495 645 042 2621 PROTECTOR,1.5A 125V

PR496 645 042 2621 PROTECTOR,1.5A 125V

Q2201 405 151 4301 TR KTC3195-Y

or 405 151 4806 TR KTC3195-O

Q2451 405 036 3702 TR 2SA1564

or 405 151 5209 TR KRA107M

or 405 000 0904 TR DTA114YS

or 405 078 2404 TR BN1A4P

Q4410 405 141 3406 TR KTA1266-GR

or 405 141 3505 TR KTA1266-Y

or 405 004 4502 TR 2SA608-F-NP

or 405 004 5004 TR 2SA608-G-NP

Q4600 405 155 0002 TR MPSA56

Q4601 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4602 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

or 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

Q4603 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

or 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

Q4700 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4701 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4751 405 151 4400 TR KTD1303

or 405 021 0204 TR 2SD1012-F-SPA

or 405 021 0600 TR 2SD1012-G-SPA

or 405 033 6706 TR 2SD1468S-R

or 405 033 6805 TR 2SD1468S-S

Q4800 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

POWER TRANSFORMER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

74 614 325 7196 ASSY,PWB,DG (Only Initial)

CN215 645 006 4760 HOLDER,FUSE

or 645 031 7903 HOLDER,FUSE

CN216 645 006 4760 HOLDER,FUSE

or 645 031 7903 HOLDER,FUSE

CN420 614 020 1215 SOCKET,2P

CN421 614 322 2262 ASSY,WIRE,PT-AMPWIRE

CN422 614 017 8203 TERMINAL BOARD

CN423 614 017 8203 TERMINAL BOARD

D4280 407 098 3300 DIODE RL153-BF-S2

D4281 407 098 3300 DIODE RL153-BF-S2

D4282 407 098 3300 DIODE RL153-BF-S2

D4283 407 098 3300 DIODE RL153-BF-S2

L4291 645 038 6053 INDUCTOR,181U

or 645 041 3087 INDUCTOR,180U

Other manuals for Sanyo DC-DA2000

Instruction Manual8 pages

Questions and Answers:

Need help?

Do you have a question about the Sanyo DC-DA2000 and is the answer not in the manual?

Sanyo DC-DA2000 Specifications

Tuner

FM frequency range	87.5 - 108 MHz
AM frequency range (9 kHz step)	522 - 1710 kHz
AM frequency range (10 kHz step)	520 - 1710 kHz

CD Player

Channels	2-channel stereo
Sampling frequency	44.1 kHz
Laser output	0.6 mW
Wave length	790 nm

Cassette Deck

Track system	4-track, 2-channel stereo
Frequency response	80 Hz to 15 kHz
Signal-to-noise ratio	40 dB
Wow/flutter	0.15% (WRMS)
Fast forward/rewind time	Approx. 110 sec. (C-60)

General

Output power	4W x 2
Power requirements	AC 230 ~ 240 V, 50 Hz
Power consumption	21 W
Dimensions	150(W) x 230(H) x 205(D) mm
Weight	2.3 kg

Speaker Systems

Type	Full range bass reflex
Unit used	10 cm cone type
Maximum power-handling capacity	8 W (peak)
Nominal impedance	4 ohms
Dimensions	145(W) x 230(H) x 170(D) mm
Weight	1.2 kg (per speaker)
