- 9 -
Com
p
ressor
(
H
)
Type C-1RN45L5
A
Cod
e
802 022 15
Rated voltage (50/60Hz
)
220-240V, 50H
z
Winding resistance C-R(Main) 5.95
䃈
C-S(Aux) 14.76
䃈
Com
p
ressor
(
L
)
Type KS240J1NS-4A1
Cod
e
7FB-0-M101-011-05
Rated voltage (50/60Hz
)
230/240V,50H
z
Winding resistance C-R(Main) 2.7
䃈
C-S(Aux) 4.9
䃈
Starting relay (H)
Type AMVL-300A
Pick up voltage 185~217VAC
Drop out voltage 60~120VAC
Starting relay (L)
Type AMVL-300TA
Pick up voltage 205~235VAC
Drop out voltage 110VAC
Overload relay (L)
Type MST16AJ120/61-9201
Action to the temp. (No current) ON:120䉝 OFF:61䉝
Action to the current (AT25Υ) 20.5A
Operation time 6~16sec.
Starting capacitor (H) Rating 40uF, 300VAC
Starting capacitor (L) Rating 160uF, 250VAC
Running capacitor (H) Rating 15uF, 400VAC
Running capacitor (L) Rating 12uF, 370VAC
Fan motor capacitor Rating
Condensing fan motor
Type SV4-11AA5P
Rating 220-240V, 10W
Capitube heater
Rating 11.2W, 230V
Resistance (AT25䉝) 4700ȍ
Temp. control relay
Type G4F-11123T
Contact capacity 20A 250VAC
Coil 12VDC
Heater relay
Type G2R-1A-T
Contact capacity 10A 250VAC
Coil 12VDC
H. comp relay
Type G4F-11123T
Contact capacity 20A 250VAC
Coil 12VDC
Switching power supply
Type ZWS10-12/J
Input
100-240VAC
Output 12VDC, 0.85A
Battery
Type 5HR-AAC-VIO3
Rating 6VDC 1100mAH
Temperature sensor
Type THC-663
Rating PT1000ȍ
Cascade sensor
Type 502AT-1
Rating 5Kȍ(25䉝)
Filter sensor
Type 502AT-1
Rating 5Kȍ(25䉝)
AT sensor
Type 502AT-1
Rating 5Kȍ(25䉝)
Battery switch
Type SLE6A2-5
Rating 250VAC, 4A
Breaker switch
Model BAM215131
Rating 250V, 15A
Door switch
Type SDKNA2070
0
Rating 5VDC, 5mA
Transformer
Type S41-U097P
V
Primary 115V, 230
V
Rating 9VAC, 0.46
A
Noise filter
Model RSAN-2020
Rating 250VAC, 20A
MDF-U55V
AC230/240V, 50Hz
Electric Parts
