Sanyo MDF-U55V User Manual

- 6 -
Cooling unit parts
Specifications
Parts descriptions
H side L side
Compressor
Type䠖C-1RN45L5A
Code䠖802 022 15
Type䠖KS240J1NS-4A1
Code䠖7FB-0-M101-011-05
Power supply Single phase 230/240V, 50Hz Single phase 230/240V, 50Hz
Refrigeration oil
Kind䠖Ze-NIUSL22SA
Charged q’ty䠖230cc
Kind䠖Ze-NIUSL22SA
Charged q’ty䠖850cc
Cooling system
Forced air cooling 䠄Partially䠅,
Pre-condenser (DSH)
Forced air cooling 䠄Partially䠅,
Oil cooler (OC)
Condenser (type) Fin and tube type Cascade condenser
Condenser
P6.35㽢3lines㽢12 columns,
Fin 38pcs.
Coil pipe (䃥6.35mm)
Pre-condenser
W250 mm
䇷
Frame pipe
䃥4.76 mm
䇷
Evaporator 䠄Type䠅
Cascade condenser
Shell and tube, 䃥80 mm
Tube on sheet type
䃥9.52 mm
Accumulator
䃥38 mm
Capillary tube
Ex. capillary
Resistance 0.765MPa 0.343MPa 34psi
Length L 2000 mm 2500 mm 500 mm
Outside diameter OD
䃥2.0 mm 䃥2.0 mm 䃥2.4 mm
Inside diameter ID
䃥0.9 mm 䃥0.9 mm 䃥1.2 mm
Refrigerant
R-404A Charged q’ty䠖 432g
n-Pentane Charged q'ty䠖 18g
R-508 Charged q’ty䠖370g
(TP5R3)
n-Pentane Charged q'ty䠖 53g
Dryer
Type: Dry core (D-SM)
Type: 4A-XH-6 Charged q’ty䠖58g
Condensing fan
䃥230mm, 4pcs. wings
Material䠖ABS
䇷
Condensing fan motor
Type䠖SV4-11AA5P
䇷

Sanyo MDF-U55V Specifications

General

Model	MDF-U55V
Category	Freezer
Type	Ultra-Low Temperature Freezer
Frequency	50Hz
Number of Doors	1
Power Supply	AC
Voltage	220V
