<Coolin
g
unit - Rear bottom side> <Coolin
g
unit - Left bottom side>
Oil separator Compressor L Compressor H Condensing fan motor
Filter sensor
Fan motor condenser 12P terminal Remote alarm terminal
Breaker switch Battery switch
<Electric Box - Ri
g
ht bottom side>
Starting relay L H comp relay Switching power supply
Starting relay H
Temp. controller PCB
Temp. control relay
Starting capacitor L
Starting capacitor H
Running capacitor L Running capacitor H
Oil separator
Heater relay
Transformer
