Sanyo PDP-42WV1 Service Manual

-11-
■ Service Adjustment Data Table
Adjustment
• All data except in gray box area is fixed. Do not change for correct operating.
• Data in gray box area is initial. Can be set according to adjustment information.
0 Sub Image PC Sub-Cont 1ah(26)
1 Sub-Bright 80h(128)
2 Sub-Color 23h(35)
3 Sub-Tint 80h(128)
4 Component Sub-Cont 1ch(28)
5 Sub-Bright 26h(38)
6 Sub-Color 1ch(28)
7 Sub-Tint 80h(128)
8 NTSC Sub-Cont 1ch(28)
9 Sub-Bright 80h(128)
10 Sub-Color 1fh(31)
11 Sub-Tint 80h(128)
12 PAL Sub-Cont 1bh(27)
13 Sub-Bright 80h(128)
14 Sub-Color 1fh(31)
15 Sub-Tint 80h(128)
16 SECAM Sub-Cont 1bh(27)
17 Sub-Bright 80h(128)
18 Sub-Color 1fh(31)
19 Sub-Tint 80h(128)
20 D PC Sub-Cont 15h(21)
21 Sub-Bright 80h(128)
22 Sub-Color 23h(35)
23 Sub-Tint 80h(128)
24 TEL TEXT Sub-Cont 1ch(28)
25 Sub-Bright 80h(128)
26 Sub-Color 20h(32)
27 Sub-Tint 80h(128)
28 HDCP Sub-Cont 15h(21)
29 Sub-Bright 80h(128)
30 Sub-Color 23h(35)
31 Sub-Tint 80h(128)
32 PC Sub-Sharp 09h(9)
33 Component D1 Sub-Sharp 15h(21)
34 Component D2 Sub-Sharp 15h(21)
35 Component D3 Sub-Sharp 15h(21)
36 Component D4 Sub-Sharp 15h(21)
37 NTSC YC Sub-Sharp 0ch(12)
38 PAL YC Sub-Sharp 0ch(12)
39 SECAM YC Sub-Sharp 0ch(12)
40 NTSC VBS Sub-Sharp 0dh(13)
41 PAL VBS Sub-Sharp 0dh(13)
42 SECAM VBS Sub-Sharp 0dh(13)
43 SCART Sub-Sharp 00h(0)
44 TEL TEXT Sub-Sharp 0ch(12)
45 Image Menu Standard AV Contrast 34h(52)
46 Bright 1fh(31)
47 Color 1fh(31)
48 Tint 00h(0)
49 Sharp 08h(8)
50 Gamma 03h(3)
51 Dynamic AV Contrast 3fh(63)
52 Bright 1fh(31)
53 Color 23h(35)
54 Tint 00h(0)
55 Sharp 08h(8)
NO. Name Mode Item Initial Data Note
