Sanyo PDP-42WV1 Service Manual

-13-
Adjustment
116 Blue 00h(0)
117 White:DVI/HDCP Red 80h(128)
118 Green 80h(128)
119 Blue 80h(128)
120 Black:DVI/HDCP Red 00h(0)
121 Green 00h(0)
122 Blue 00h(0)
123 Color Temp AV High Red 76h(118)
124 Green 7ah(122)
125 Blue 80h(128)
126 AV Mid Red 80h(128)
127 Green 80h(128)
128 Blue 80h(128)
129 AV Low Red 80h(128)
130 Green 7eh(126)
131 Blue 73h(115)
132 PC High Red 76h(118)
133 Green 7ah(122)
134 Blue 80h(128)
135 PC Mid Red 80h(128)
136 Green 80h(128)
137 Blue 80h(128)
138 PC Low Red 80h(128)
139 Green 7eh(126)
140 Blue 73h(115)
141 Sound Device Sound AGC On/Off 00h(0)
142 Level 01h(1)
143 Sound BCSB/Bass Sub-Set 01h(1)
144 Sound BCST/Treb Sub-Set 01h(1)
145 Wide Pc Just Width +/- Flag 00h(0)
146 Data High 00h(0)
147 Data Low 00h(0)
148 Video Just Width +/- Flag 00h(0)
149 Data High 27h(39)
150 Data Low 00h(0)
151 PDP Error Diffusion On/Off SW 02h(2)
152 H Start Pos 1 Data 20h(32)
153 H Start Width 1 Data bah(186)
154 H Start Pos 2 Data 96h(150)
155 H Start Width 2 Data 40h(64)
156 Threshold PC MPD 01h(1)
157 AV MPD 01h(1)
158 50Hz / 50Hz - 100 F SW 04h(4)
159 ABL Level Hi Data 23h(35)
160 ABL Level Lo Data 19h(25)
161 H Start Width Top 1 Bit 01h(1)
162 H Start Width Top 2 Bit 01h(1)
163 Side Bar Off Border Color Type 1 Red 00h(0)
164 Green 00h(0)
165 Blue 00h(0)
166 Side Bar On Border Color Type 2 Red 40h(64)
167 Green 40h(64)
168 Blue 40h(64)
169 Over Scan 525i VBS H Start + 1fh(31)
170 V Start + 09h(9)
171 Width + 09h(9)
172 Height + 07h(7)
173 525i YC H Start + 1fh(31)
174 V Start + 09h(9)
175 Width + 09h(9)
NO. Name Mode Item Initial Data Note
