Sanyo PDP-42WV1 Service Manual

-14-
Adjustment
176 Height + 07h(7)
177 525i Component H Start + 19h(25)
178 V Start + 0fh(15)
179 Width + 07h(7)
180 Height + 05h(5)
181 525p Component H Start + 1dh(29)
182 V Start + 0ah(10)
183 Width + 07h(7)
184 Height + 05h(5)
185 625i VBS H Start + 14h(20)
186 V Start + 1fh(31)
187 Width + 0ah(10)
188 Height + 07h(7)
189 625i YC H Start + 14h(20)
190 V Start + 1fh(31)
191 Width + 0ah(10)
192 Height + 07h(7)
193 625i Component H Start + 2fh(47)
194 V Start + 14h(20)
195 Width + 08h(8)
196 Height + 06h(6)
197 625p Component H Start + 2fh(47)
198 V Start + 14h(20)
199 Width + 08h(8)
200 Height + 08h(8)
201 1080i Component H Start + 2ch(44)
202 V Start + 20h(32)
203 Width + 05h(5)
204 Height + 05h(5)
205 1080i(50) Component H Start + 2dh(45)
206 V Start + 18h(24)
207 Width + 05h(5)
208 Height + 04h(4)
209 720p Component H Start + 1dh(29)
210 V Start + 12h(18)
211 Width + 05h(5)
212 Height + 05h(5)
213 720p(50) Component H Start + 2ch(44)
214 V Start + 13h(19)
215 Width + 05h(5)
216 Height + 05h(5)
217 540p Component H Start + 2ch(44)
218 V Start + 10h(16)
219 Width + 05h(5)
220 Height + 06h(6)
221 540p(50) Component H Start + 2dh(45)
222 V Start + 0eh(14)
223 Width + 05h(5)
224 Height + 06h(6)
225 Image AGC VPC Start Value 27h(39)
226 Limit Value 3fh(63)
227 Step Size 01h(1)
228 Stop Range 08h(8)
229 AD9884 Start Value a7h(167)
230 Limit Value 6ah(106)
231 Step Size 04h(4)
232 Stop Range 08h(8)
233 Max Peak PC Peak e6h(230)
234 TV/VBS/YC d7h(215)
235 D2 - D4 Peak d7h(215)
NO. Name Mode Item Initial Data Note
