-10-
Mechanical disassemblies
9. Projection lens and Assembly Panel-Prism removal
1. Remove four screws and remove projection lens.
2. Remove three screws and remove Assembly Panel-
Prism.
See figure right.
Caution :
Don't disassemble Assembly-Panel-Prism other wise
parts may damaged
Ass'y P/Prism
Projection lens
Never touch the electrode
of flexible cables.
