111 TI_C_GAIN_SLOPE, 0 0 ~ 7 127
112 TI_C_GAIN_SEL, 0 0 ~ 7 128
113 PEAK_H_BPF_SEL, 0 / 1 0 ~ 3 129 (reg A) NTSC,PAL,480p,575p / 720p,1035i,1080i,1080i50
114 PEAK_H_CORR, 3 / 0 0 ~ 255 130
115 PEAK_H_GAIN, - / - 0 ~ 63 131
116 PEAK_H_GAIN_TH, 0 / 0 0 ~ 255 132
117 PEAK_H_GAIN_SLOPE, 2 / 2 0 ~ 7 133
118 PEAK_H_GAIN_SEL, 1 / 1 0 ~ 3 134
119 PEAK_H_MAX, 255 / 255 0 ~ 255 135
120 Y2G, - / - 0 ~ 1023 136 / 137 (reg B) NTSC,PAL,480p,575p / 1035i,1080i,1080i50,720p
121 CB2G, - / - 0 ~ 1023 138 / 139
122 CR2G, - / - 0 ~ 1023 140 / 141
123 Y2B, - / - 0 ~ 1023 142 / 143
124 CB2B, - / - 0 ~ 1023 144 / 145
125 CR2B, - / - 0 ~ 1023 146 / 147
126 Y2R, - / - 0 ~ 1023 148 / 149
127 CB2R, - / - 0 ~ 1023 150 / 151
128 CR2R, - / - 0 ~ 1023 152 / 153
129 G_Y_OUT_OS, 0 0 ~ 255 154 (reg C) fix
130 G_Y_OUT_MIN., 0 0 ~ 255 155
131 G_Y_OUT_DC, 0 0 ~ 255 156
132 G_Y_OUT_MAX, 255 0 ~ 255 157
133 B_CB_OUT_OS, 0 0 ~ 255 158
134 B_CB_OUT_MIN., 0 0 ~ 255 159
135 B_CB_OUT_DC, 0 0 ~ 255 160
136 B_CB_OUT_MAX, 255 0 ~ 255 161
137 R_CR_OUT_OS, 0 0 ~ 255 162
138 R_CR_OUT_MIN., 0 0 ~ 255 163
139 R_CR_OUT_DC, 0 0 ~ 255 164
140 R_CR_OUT_MAX, 255 0 ~ 255 165
141 CINEMA_START_H, 0 / 0 / 0 0 ~ 255 166 (reg D) IP-ON=NTSC / IP-ON=NTà»äO / IP-OFF
142 CINEMA_SIZE_H, 160 / 0 / 0 0 ~ 255 167
143 CINEMA_START_V, 1 / 0 / 0 0 ~ 255 168
144 CINEMA_SIZE_V, 60 / 0 / 0 0 ~ 255 169
145 CINEMA_MOTION_TH, 16 / 0 / 0 0 ~ 255 170
146 CINEMA_DET_TH, 384 / 0 / 0 0 ~ 65535 171 / 172
147 CINEMA_DET_FIELD, 7 / 0 / 0 0 ~ 7 173
148 CINEMA_CTL_SWAP, 20 / 0 / 0 0 ~ 31 174
149 CINEMA_CTL_Y, 0 / 1 / 1 0 or 1 175-1
150 CINEMA_CTL_C, 1 / 1 / 1 0 or 1 175-0
151 EXT_CINEMA_DET, 0 / 0 / 0 0 or 1 176-2
152 EXT_CINEMA_MODE, 0 / 0 / 0 0 or 1 176-1
153 EXT_CINEMA_SWAP, 0 / 0 / 0 0 or 1 176-0
154 STINT 0 / 0 / 0 0 ~ 31 177 (reg E) without RGB = NTSC,PAL,480p,575p / without RGB = 720p,1035i,1080i,1080i50 / RGB
155 SCOL 140 / 140 / 180 0 ~ 255 178
156 CB2B_STD 454 / 454 / 454 0 ~ 1023 179 / 180
157 CR2B_STD 0 / 0 / 0 0 ~ 1023 181 / 182
158 CB2R_STD 0 / 0 / 0 0 ~ 1023 183 / 184
159 CR2R_STD 359 / 359 / 359 0 ~ 1023 185 / 186
160 CB2G_STD 1015 / 105 / 1015 0 ~ 1023 187 / 188
161 CR2G_STD 842 / 842 / 842 0 ~ 1023 189 / 190
162 S_SHP 8 / 10 / 0 0 ~ 63 191
Group: 21 IP (MB40C348)
0 V_AMP 0 0 or 1 adr0-2
1 DSEL 1 0 or 1 adr0-1
2CE00 or 1 adr0-0
3 COUNTER_W 64 0 ~ 4095 adr1,adr2(3-0)
4 ADC_OUT 0 0 or 1 adr3-7
5HSYNC_POL 1 0 or 1 adr3-6
6CLK_DELAY 0 0 ~ 63 adr3(5-0)
7 DSYNC_DELAY 1 0 ~ 3 adr4(7-6)
8 ADCLK_B 1 0 or 1 adr4-5
9 ADCLK_A 1 0 or 1 adr4-4
10 DSYNC_B 1 0 or 1 adr4-3
11 DSYNC 1 0 or 1 adr4-2
12 CLK_B 1 0 or 1 adr4-1
13 CLK 1 0 or 1 adr4-0
14 DIVIDER 0 0 ~ 3 adr5(7-6)
15 VCO_CHG 0 0 or 1 adr5-5
16 CURRENT 0 0 or 3 adr5(4-3)
17 counter 1 0 or 1 adr5-2
18 out_clk 0 0 or 1 adr5-1
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
-12-
