-7-
Electrical Adjustments
Group: 0 TA1370
0 SEP_LEV 3 / 3 / 3 0 ~ 3 YCbCr-1080i,1035i,720p / RGB-1080i,1035i,720p / others
1 YCLP_PHS 0 / 1 / 1 0 or 1 YCbCr-1080i,1035i,720p / RGB-1080i,1035i,720p / others
2 HD_PHASE 37 / 40 / 36 / 37 / 40 / 0 ~ 63 YCbCr-1080i,1035i / 720p / 1080i_50 / RGB-1080i / RGB-720p /
36 / 37 / 37 / 32 RGB-1080i_50 / 575p / 480p / others
3 V_FREQ - - Read only
4H_FREQ - -
5 HD_IN - -
Group: 1 uPD64083
0 NRMD 0 0 ~ 3
1 HDP 4 0 ~ 7
2 CDL 4 0 ~ 7
3DYCOR 4 0 ~ 15 DY detect coring level (Y movement detect coring)
4DYGAIN 15 0 ~ 15 DY detect gain (Y movement detect gain)
5 DCCOR 2 0 ~ 15 DC detect coring level (C movement detect coring)
6 DCGAIN 13 0 ~ 15 DC detect gain (C movement detect gain)
7VAPGAIN 3 0 ~ 15
8VAPINV 2 0 ~ 15
9 YPFT 3 0 ~ 3
10 YPFG 12 0 ~ 15
11 V1PSEL 3 0 ~ 3
12 VEGSEL 3 0 ~ 3
13 CC3N 0 0 or 1
14 SELD2FH 1 0 or 1
15 SELD1FL 1 0 or 1
16 YHCOR 0 0 ~ 3
17 HPLLFG 1 0 or 1
18 PLLFS 1 0 or 1
19 KILR 3 0 ~ 15
20 HSSL 12 0 ~ 15
21 VSSL 3 0 ~ 15
22 BGPS 7 0 ~ 15
23 BGPW 3 0 ~ 15
Group: 2 TB1274AF
0 TINT 32 0 ~ 63
1 SHP_EQ 2 0 ~ 3
2 SHP_FO 2 0 ~ 3
3 SHP_GAIN 11 / 11 / 8 / 6 0 ~ 15 Video NT / PAL,PALM,PALN / SECAM,BW60,BW50 / NT443 /
6 / 9 / 8 / 8 PAL60 / S-Video / YCbCr / Scart
4 Y_OUT_LEVEL 33 / 31 / 32 / 32 / 35 / 0 ~ 63 Video NT / NT443 / PAL,PALM,PALN / PAL60 / SECAM,BW /
0.7V 31 / 31 / 32 / 32 S-Video NT,BW / NT443 / PAL,PALM,PALN / PAL60
32 / 35 / 38 SECAM / YCbCr / Scart
5 C_OUT_LEVEL 25 / 24 / 31 / 25 / 41 / 0 ~ 63 Video NT / NT443 / PAL,PALM,PALN / PAL60 / SECAM,BW /
0.6V 26 / 26 / 32 / 25 / S-Video NT,BW / NT443 / PAL,PALM,PALN / PAL60
42 / 35 / 35 / 35 SECAM / 480i / 575i / Scart
6 Y_DELAY 5 / 5 / 4 / 4 / 4 / 0 ~ 15 Video NT,BW60 / PAL,PALM,PALN,BW50 / SECAM / NT443 / PAL60
4 / 4 / 3 / 3 / 4 S-Video NT,BW60 / PAL,PALM,PALN,BW50 / SECAM / NT443 / PAL60
7 COL_SYS - - Read Only
8X’TAL - -
9 NOISE_DET - -
10 V_FREQ - -
11 Vert. Std - -
12 CID - -
13 V_SIG - -
14 MVM 0 0 or 1
15 AFC_GAIN 1 0 ~ 3
16 SECAM_GP, SECAM_ID 7 0 ~ 15
17 LPF 1 / 1 0 or 1 Not-Scart / Scart
Group: 3 CXA2151
0MAT OUT 0 / 0 / 0 / 2 / 1 0 ~ 3 RGB / YCbCr 480i&575i / YCbCr 480p&575p / YCbCr 1080i&720p / YCbCr 1035i
1 V_TC 0 / 0 / 0 / 0 / 0 ~ 3 RGB-480i,575i / 480p,575p / 720p,1080i / 1035i
0 / 0 / 0 / 0 YCbCr-480i,575i / 480p,575p / 720p,1080i / 1035i
2 HSEP_SEL 0 / 0 / 0 / 0 / 0 or 1 RGB-480i,575i / 480p,575p / 720p,1080i / 1035i
0 / 0 / 0 / 0 YCbCr-480i,575i / 480p,575p / 720p,1080i / 1035i
3 HD_TC 0 / 0 / 0 / 0 / 0 or 1 RGB-480i,575i / 480p,575p / 720p,1080i / 1035i
0 / 0 / 0 / 0 YCbCr-480i,575i / 480p,575p / 720p,1080i / 1035i
No. Adjustment Item Initial Value Range Input source / Description
● Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjust-
ment items indicated with “✻” are required to readjust following
to the “Electrical adjustments”. Other items should be used with
the initial data value.
To Next Page
