Sanyo PLC-XR201 User Manual

-39-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
1 Video Motion Sensitivity
Film Detection Sensitivity
<VOFSTVT>
4 1 - 5
2 Video Motion Threshold Low <VOFTHRDA> 120 0 - 32767
3
Video Motion Threshold
High
<VOFTHRDB> 180 0 - 32767
4 Global Motion Threshold <GMDTHRD> 124 0 - 1024
5 23Film Mode Threshold <FILMTHRD23> 100 0 - 32767
6
Global Motion Window Start
X
<GMDSTARX> 10 0 - 2047 Range of detective for Film mode
7
Global Motion Window Stop
X
<GMDSTOPX> 10 0 - 2047 Range of detective for Film mode
8
Global Motion Window Start
Y
<GMDSTARY> 10 0 - 1023 Range of detective for Film mode
9
Global Motion Window Stop
Y
<GMDSTOPY> 10 0 - 1023 Range of detective for Film mode
Group
60
0 Center Contrast 512/556/534/534/492/492 0 - 1023
Video(S-Video) / Component /
SCART /
ANALOG / DIGITAL / HDCP
Setting Value=
(MENU Value - MENU Center Value
) x Alpha / 10 + Center
[Setting Value to PW]
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0
1 Center Brightness 512/480/512/500/512/512 0 - 1023
2 Center Color 512/534/512/512/512/512 0 - 1023
3 Center Tint 90/90/90/90/90/90 0-180
4 Center Sharpness 16/16/16/16/16/16 16
5 Alpha Contrast 40/40/40/40/40/40 0-1000
6 Alpha Brightness 115/115/115/115/115/115 0-1000
7 Alpha Color 70/70/70/70/70/70 0-1000
8 Alpha Tint 10/10/10/10/10/10 0-1000
9 Alpha Sharpness 10/10/10/10/10/10 0-1000
10 Center WB Red 512/512/512/512/512/512 0-1023 Composite / S-Video / Component /
Digital /D-RGB-Video /AnalogRGB /
RGB-Video / HDCP-PC /HDCP-AV
/SCART/ PJ-Net
Setting Value=
MENU Value - MENU Center Value )
x Alpha / 10 + Center
WB R/G/B [Max] 1023 [Min] 0
11 Center WB Green 512/512/512/512/512/512 0-1023
12 Center WB Blue 512/512/512/512/512/512 0-1023
13 Alpha WB Red 40/40/40/40/40/40 0-1023
14 Alpha WB Green 40/40/40/40/40/40 0-1023
15 Alpha WB Blue 40/40/40/40/40/40 0-1023
Group
100
Panel Service
0 G-SubGain
2048/2048/2048/2048/2020/2020/
1860/1950/2048/2048/2048/2048/
2020/2020/1860/1950/
0-4095
PCStandard/PCDynamic/PCReal/
PCBlackBoard/PCColBoaR/PCCol-
BoaG/PCColBoaB/PCColBoaY/
AVStandard/AVDynamic/AVCinema/
AVBlackBoard/AVColBoaR/AVCol-
BoaG/AVColBoaB/AVColBoaY
1 R-SubGain
2048/2048/2048/2048/1900/2048/
2000/2048/2048/2048/2048/2048/
1900/2048/2000/2048
0-4095
2 B-SubGain
2048/2048/2048/2048/2048/1980/
2048/2000/2048/2048/2048/2048/
2048/1980/2048/2000
0-4095
3 G-SubBright 0/0/0/0/0/0/0/0/0/0/0/0/0/0/0/0 0-4095
PCStandard/PCDynamic/PCReal/
PCBlackBoard/PCColBoaR/PCCol-
BoaG/PCColBoaB/PCColBoaY/
AVStandard/AVDynamic/AVCinema/
AVBlackBoard/AVColBoaR/AVCol-
BoaG/AVColBoaB/AVColBoaY/
4 R-SubBright 0/0/0/0/0/0/0/16/0/0/0/0/0/0/0/16 0-4095
5 B-SubBright 0/0/0/0/16/0/16/0/0/0/0/0/16/0/16/0 0-4095
6 G-GammaShift 0 0-4095
PC/AV
Center=512
R] and [B] are linked with [G]
7 R-GammaShift 0 0-4095
8 B-GammaShift 0 0-4095
9 G-ReferH 4088/4088 0-4095
[R] and [B] are linked with [G] Scan
Direction (Front/Rear)
10 G-ReferL 0/0 0-4095
[R] and [B] are linked with [G] Scan
Direction (Front/Rear)
11 R-ReferH 4088/4088 0-4095 Scan Direction (Front/Rear)
12 R-ReferL 0/0 0-4095 Scan Direction (Front/Rear)
13 B-ReferH 4088/4088 0-4095 Scan Direction (Front/Rear)
14 B-ReferL 0/0 0-4095 Scan Direction (Front/Rear)
15 DXOutR 230 0-1023
16 DXOutG 230 0-1023
17 DXOutB 230 0-1023
18 H_Change_Pos 27 0-255
19 SH_Base 273 0-4095
20 NRG_Pos 30 0-127
21 NRG_Width 38 0-255
22 OSD_Pos 2 0-3
23 OSD_Ptn 0 0-9
24 GammaCtrl 1 0-1
25 REF_GatePos 15 0-1023
