Sanyo PLC-XR201 User Manual

Key No. Part No. Description Key No. Part No. Description
KR5-XR20100, KS5-XR25100
-85-
Electrical Parts List
D1003 307 205 5216 DIODE RB521S-30-TE61
D1004 307 205 5216 DIODE RB521S-30-TE61
D2025 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D2891 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D2892 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D3606 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3613 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3614 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3617 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3621 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3622 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3623 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3626 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3628 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3644 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D5061 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D5062 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D5625 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D591 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D592 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6801 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6802 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6803 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6831 408 068 5508 LED KPT-2012YC
D6833 307 203 7816 LED SML-210LT T86 M
D6835 408 068 5201 LED KPTB-1612ESGC
D6840 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6841 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6842 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6845 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6846 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6850 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6851 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6852 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6853 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6854 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D7812 407 267 5114 DIODE SS3P4-E3/84A
D7862 407 267 5114 DIODE SS3P4-E3/84A
D8801 307 209 7513 LED SML-210YT T86 L
D8902 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
MISCELLANEOUS
K10A 952 001 8601 SOCKET,D-SUB 15P
K10B 952 001 8571 SOCKET,D-SUB 15P
K20B 652 002 1808 JACK,PHONE D3.6
652 002 4847 JACK,PHONE D3.6
K40B 652 002 8135 PLUG,D-SUB 9P
K9602 645 093 6760 TRANS,PULSE
SC1030 945 076 3503 SURGE-ABSORBER
SC1041 945 076 3503 SURGE-ABSORBER
SC1081 945 076 3503 SURGE-ABSORBER
SC1091 945 076 3503 SURGE-ABSORBER
SC2003 945 076 3503 SURGE-ABSORBER
SC2021 945 076 3503 SURGE-ABSORBER
SC2023 945 076 3503 SURGE-ABSORBER
SC2031 945 076 3503 SURGE-ABSORBER
SC2041 945 076 3503 SURGE-ABSORBER
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6810 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X8802 945 083 7556 OSC,CRYSTAL 25.0MHZ
X9885 945 060 9900 OSC,CERAMIC 8.00MHZ
655 002 7887 ASSY,PWB,POWER KR5AC
TRANSISTOR
Q611 305 140 3707 TR 2SK2698
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
