Key No. Part No. Description Key No. Part No. Description
KR5-XR20100, KS5-XR25100
-87-
Electrical Parts List
307 149 0810 DIODE 1SS355-TE-17
D631 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D632 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D633 308 061 8806 DIODE EG01C
D634 307 206 5413 ZD UDZS-TE-178.2B
D651 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D661 407 267 3100 DIODE SG10SC9M
D662 407 267 3001 DIODE SG10SC6M
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D664 307 210 5416 DIODE RB551V-30-TE-17
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
!F601 423 034 4101 FUSE 250V 6.3A
323 021 7804 FUSE 250V 6.3A
!F631 324 006 1305 FUSE 250V 2.5A
Q611F 645 098 1715 CORE,FERRITE
!PC661 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
! PC662 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC663 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PTH611 308 037 5501 THERMISTOR NTPDB5R0LDHB0
!PTH641 408 062 4606 TH PRF18BD471QB1RB
!SW601A 652 003 0244 ASSY,WIRE(SW601)
655 002 8396 ASSY,PWB R/C KR5AC
CAPACITOR
C2901 303 358 8319 CERAMIC 1U K 10V
C2902 303 157 6615 CERAMIC 470P K 50V
C2903 303 230 3616 TA-SOLID 47U M 6.3V
303 384 4712 TA-SOLID 47U M 6.3V
C8843 303 298 9612 CERAMIC 0.1U K 16V
RESISTOR
R2901 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2903 301 255 6513 MT-GLAZE 100 JA 1/10W
R8855 301 162 2219 MT-GLAZE 10 JA 1/10W
R8856 301 162 2219 MT-GLAZE 10 JA 1/10W
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
PACKING MATERIALS
610 346 2332 CARTON CASE-KR5AD
(FOR KR5-XR20100)
610 346 2356 CARTON CASE-KS5AD
(FOR KS5-XR25100)
610 347 4762 CUSHION SPACER LEFT-KR5AC
610 347 4755 CUSHION SPACER RIGHT-KR5AC
610 347 5608 CUSHION BTM-KR5AC
610 345 2524 CUSHION TOP-KR5AC
645 097 3987 POLY BAG-0550X0600*NC*R8P
ACCESSORIES
OWNER'S MANUAL
610 343 6456 CD-ROM(PJ NW MANAGER)
610 346 3261 CD-ROM,OWNERS MANUAL-KR5AD
655 003 3475 SAFETY MANUAL-KG5AC
655 002 9935 SETUP INST-KR5AD
REMOTE CONTROL
645 099 3213 ASSY,REMOCON CXZR
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
!US 645 101 1213 CORD,POWER-1.8MK,US
!EU 645 101 1220 CORD,POWER-1.8MK,EU
!US 645 101 1237 CORD,POWER-1.8MK,UK
MISCELLANEOUS
610 343 0249 STRAP CAP-KT7AC
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
945 023 4959 CORE,CLAMP
652 002 9552 CABLE,INTERFACE VGA
