Sanyo PLC-XT35L Service Manual

Key No. Part No. Description Key No. Part No. Description
KP3-XT3500, KP3-XT35L00
-131-
Electrical Parts List
SC4076 945 076 3503 SURGE-ABSORBER
SC4078 945 076 3503 SURGE-ABSORBER
SC4079 945 076 3503 SURGE-ABSORBER
SW4061 945 010 7659 SWITCH,PUSH 1P-1TX1
610 335 3166 ASSY,PWB,NETWORK JOINT KP3AL
TRANSISTOR
Q3031 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC3031 309 673 9819 IC PQ070XNA1ZPH
IC3041 309 673 9819 IC PQ070XNA1ZPH
CAPACITOR
C3031 303 358 8319 CERAMIC 1U K 10V
C3032 303 358 8319 CERAMIC 1U K 10V
C3033 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C3041 303 358 8319 CERAMIC 1U K 10V
C3042 303 358 8319 CERAMIC 1U K 10V
C3043 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
RESISTOR
R3031 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
R3032 301 150 5918 MT-GLAZE 10K JA 1/10W
R3033 301 264 1813 MT-GLAZE 1K FA 1/10W
R3034 301 255 9019 MT-GLAZE 82 JA 1/10W
R3036 301 264 4210 MT-GLAZE 1.6K FA 1/10W
R3037 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
R3038 301 150 5918 MT-GLAZE 10K JA 1/10W
R3039 301 150 5918 MT-GLAZE 10K JA 1/10W
R3041 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
R3042 301 150 5918 MT-GLAZE 10K JA 1/10W
R3043 301 264 1813 MT-GLAZE 1K FA 1/10W
R3044 301 256 6512 MT-GLAZE 68 JA 1/10W
R3046 301 264 8812 MT-GLAZE 3K FA 1/10W
R3047 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
DIODE
D3031 307 205 5216 DIODE RB521S-30-TE61
D3041 307 163 0414 DIODE 1SS352-(TPH3)
610 335 3135 ASSY,PWB,R/C. FRONT KP3AL
CAPACITOR
C2821 303 398 4111 ELECT 47U M 16V
303 387 6515 ELECT 47U M 16V
C2822 303 157 6615 CERAMIC 470P K 50V
C2823 303 358 8319 CERAMIC 1U K 10V
RESISTOR
R2821 301 256 5614 MT-GLAZE 47 JA 1/10W
R2822 301 162 2219 MT-GLAZE 10 JA 1/10W
MISCELLANEOUS
A2821 945 082 0466 UNIT,REMOCON RECEIVER
PACKING MATERIALS
610 331 3030 SPACER LNS PACKING MZ7A
610 338 6362 CARTON CASE COM-KP3A
FOR PLC-XT35
610 336 1383 CARTON CASE COM-KP3AL
FOR PLC-XT35L
610 331 3016 CASE ACCESSORY-MZ7A
610 335 0479 CUSHION SPACER-MZ7A
610 331 2842 CUSHION FNT-MZ7A
645 096 4459 POLY BAG-0700X0600*NC*R8P
ACCESSORIES
OWNER’S MANUAL
610 336 1567 SETUP INST MANUAL-KP3A
610 336 1659 CD-ROM,OWNERS MANUAL-KP3A
REMOTE CONTROL
945 087 1468 ASSY,REMOCON CXTK
910 319 1820 RC-BATTERY LID-CXSP
! AC CORD
US 945 064 6363 CORD,POWER-3.0MK,US
EU 945 054 1156 CORD,POWER-3.0MK
UK 945 054 1149 CORD,POWER-3.138MK
MISCELLANEOUS
945 039 7210 CABLE,MOUSE SRAL
945 063 6937 CABLE,USB
945 063 6944 CABLE,USB
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
