Sanyo PLC-XT35L Service Manual

-63-
Electrical Adjustment
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
Group/
Item
Item Name Function Initial Range Note
Group 0 AD Converter (PW190)
0 ADC G-OFFSET PC 128 0 - 255 * G-Pedestal Adjustment
1 ADC R-OFFSET PC 128 0 - 255 * R-Pedestal Adjustment
2 ADC B-OFFSET PC 128 0 - 255 * B-Pedestal Adjustment
3 ADC G-GAIN PC 50 0 - 255 * Gain Adjustment [PC]
4 ADC R-GAIN PC 40 0 - 255 * Gain Adjustment [PC]
5 ADC B-GAIN PC 40 0 - 255 * Gain Adjustment [PC]
6 GRAAFLTR/RBAAFLTR Green (Red and Blue) Anti-Alias Filter 4 / R / R 0 - 7
Composite & S-Video / Component / PC
*R: Read only value
7
GRNAADWNSMPL / RBAAD-
WNSMPL
Green (Red and Blue) Anti-Alias Downs-
ample
0 / R / R 0 - 3
8 GRNAAHF / RBAAHF
Green (Red and Blue) Anti-Alias High
Frequency
3 / R / R 0 - 3
10 SOGTH
PC
SyncOn Green Threhould
4 0 - 15
11 SOGHYSDIS
PC
Sync On Green Hsysterisis Enable
0 0 - 1
12 HS1TH 4 0 - 7
13 HS0TH 4 0 - 7
100 PreCoast PC Signal 3 0 - 63
101 PostCoast PC Signal 8 0 - 63
120 PreCoast PC Video 480i 7 0 - 63
121 PostCoast PC Video 480i 13 0 - 63
122 PreCoast PC Video 575i 7 0 - 63
123 PostCoast PC Video 575i 13 0 - 63
124 PreCoast PC Video 480p 7 0 - 63
125 PostCoast PC Video 480p 13 0 - 63
126 PreCoast PC Video 575p 7 0 - 63
127 PostCoast PC Video 575p 13 0 - 63
128 PreCoast PC Video 720p 60Hz 7 0 - 63
129 PostCoast PC Video 720p 60Hz 13 0 - 63
130 PreCoast PC Video 720p 50Hz 7 0 - 63
131 PostCoast PC Video 720p 50Hz 13 0 - 63
132 PreCoast PC Video 1080i 60Hz 7 0 - 63
133 PostCoast PC Video 1080i 60Hz 13 0 - 63
134 PreCoast PC Video 1080i 50Hz 7 0 - 63
135 PostCoast PC Video 1080i 50Hz 13 0 - 63
136 PreCoast PC Video 1035i 7 0 - 63
137 PostCoast PC Video 1035i 13 0 - 63
138 PreCoast PC Video 1080p 60Hz 7 0 - 63
139 PostCoast PC Video 1080p 60Hz 13 0 - 63
140 PreCoast PC Video 1080p 50Hz 7 0 - 63
141 PostCoast PC Video 1080p 50Hz 13 0 - 63
142 PreCoast PC Video 1080p 30Hz 7 0 - 63
143 PostCoast PC Video 1080p 30Hz 13 0 - 63
144 PreCoast PC Video 1080p 25Hz 7 0 - 63
145 PostCoast PC Video 1080p 25Hz 13 0 - 63
146 PreCoast PC Video 1080p 24Hz 7 0 - 63
147 PostCoast PC Video 1080p 24Hz 13 0 - 63
150 PreCoast YCbCr 480i 7 0 - 63
151 PostCoast YCbCr 480i 13 0 - 63
152 PreCoast YCbCr 575i 7 0 - 63
153 PostCoast YCbCr 575i 13 0 - 63
154 PreCoast YCbCr 480p 7 0 - 63
155 PostCoast YCbCr 480p 13 0 - 63
156 PreCoast YCbCr 575p 7 0 - 63
157 PostCoast YCbCr 575p 13 0 - 63
158 PreCoast YCbCr 720p 60Hz 7 0 - 63
159 PostCoast YCbCr 720p 60Hz 13 0 - 63
160 PreCoast YCbCr 720p 50Hz 7 0 - 63
161 PostCoast YCbCr 720p 50Hz 13 0 - 63
