-133-
Mechanical Parts List
KP3-XT3500, KP3-XT35L00
L01
C07
L01-2
L01-1
L11
M01-3
M01-2
M01-1
Optical engine_Lens shift assembly
Optical engine_Lens assembly
Condenser lens-out assembly
Relay lens-out assembly
S03
S03
L01-3
M01
