-65-
Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
Group 42 Deinterlacer setting Effective only for Progressive ON-L2 mode.
0 Motion Adaptive Weight Value <KDEINT> 0 0 - 255
1 Angle Interpolation Level 0 : Conservative <====> 4 : Aggressive 2 0 - 4
2 CUE Low Pass Filter Enable <CUELPFEN> 0 0 - 1
Group 43 Deinterlacer setting Effective only for Progressive ON/Film mode.
0 Motion Adaptive Weight Value <KDEINT> 30 0 - 255
1 Angle Interpolation Level 0 : Conservative <====> 4 : Aggressive 4 0 - 4
2 CUE Low Pass Filter Enable <CUELPFEN> 0 0 - 1
Group 45 Noise Reduction (Time) Effective only for N.R: Off
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 0 - 255
Group 47 Noise Reduction (Time) Effective only for N.R L1
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 50 0 - 255
Group 49 Noise Reduction (Time) Effective only for N.R L2
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 100 0 - 255
Group 50 2:2pull down setting
0 22Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 4 1 - 5
1 22Film Mode Threshold Low <FILMTHRD22A> 80 0 - 32767
2 22Film Mode Threshold High <FILMTHRD22B> 120 0 - 32767
3 VOFTHR13 <VOFTHR13> 124 0 - 1023 * Read only
4 VOFTHR12 <VOFTHR12> 124 0 - 1023 * Read only
5 VOFTHR23 <VOFTHR23> 124 0 - 1023 * Read only
6 Video Motion Window Start X <VOFSTARX> 10 0 - 2047 Range of detective for Film mode
7 Video Motion Window Stop X <VOFSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Video Motion Window Start Y <VOFSTARY> 10 0 - 1023 Range of detective for Film mode
9 Video Motion Window Stop Y <VOFSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 51 2:3pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 4 1 - 5
1 Video Motion Sensitivity Film Detection Sensitivity <VOFSTVT> 4 1 - 5
2 Video Motion Threshold Low <VOFTHRDA> 120 0 - 32767
3 Video Motion Threshold High <VOFTHRDB> 180 0 - 32767
4 Global Motion Threshold <GMDTHRD> 124 0 - 1024 * Read only
5 23Film Mode Threshold <FILMTHRD23> 100 0 - 32767
6 Global Motion Window Start X <GMDSTARX> 10 0 - 2047 Range of detective for Film mode
7 Global Motion Window Stop X <GMDSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Global Motion Window Start Y <GMDSTARY> 10 0 - 1023 Range of detective for Film mode
9 Global Motion Window Stop Y <GMDSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 55 * Not used
Group 60 Image
0 Center Contrast 578/578/534/534/492/492 0 - 1023
Video(S-Video) / Component / SCART /
ANALOG / DIGITAL / HDCP
Setting Value=
(MENU Value - MENU Center Value ) x
Alpha / 10 + Center
[Setting Value to PW]
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0
1 Center Brightness 512/512/512/500/512/512 0 - 1023
2 Center Color 512/534/512/512/512/512 0 - 1023
3 Center Tint 90/90/90/90/90/90 0-180
4 Center Sharpness 16/16/16/16/16/16 Fixed 16
5 Alpha Contrast 40/40/40/40/40/40 0-1000
6 Alpha Brightness 140/140/140/140/140/140 0-1000
7 Alpha Color 160/160/160/160/160/160 0-1000
8 Alpha Tint 10/10/10/10/10/10 0-1000
9 Alpha Sharpness 10/10/10/10/10/10 0-1000
To Next Page
