Sanyo PLC-XU75

-39-
Group/
Item
ITEM NAME FUNCTION INITIAL RANGE NOTE
164 G-DCOffset-P9 0/0 0-511
165 G-DCOffset-P10 0/0 0-511
166 G-DCOffset-P11 0/0 0-511
167 G-DCOffset-P12 22 / 22 0-511
168 B-DCOffset-PGain 0/0 0-255
169 B-DCOffset-P1 4 / 4 0-511
170 B-DCOffset-P2 0/0 0-511
171 B-DCOffset-P3 0/0 0-511
172 B-DCOffset-P4 0/0 0-511
173 B-DCOffset-P5 0/0 0-511
174 B-DCOffset-P6 0/0 0-511
175 B-DCOffset-P7 0/0 0-511
176 B-DCOffset-P8 0/0 0-511
177 B-DCOffset-P9 0/0 0-511
178 B-DCOffset-P10 0/0 0-511
179 B-DCOffset-P11 0/0 0-511
180 B-DCOffset-P12 22 / 22 0-511 Scan Direction (Front/Rear)
181 ENBX-R
0
0-127
182 ENBX-G
0
0-127
183 ENBX-B
0
0-127
184 DXOutPos
0
0-1
PLC-XU78
Group101 : Panel Service(6150/1060)
0 R-LCCOM 255 0-511 *Common Center Adjustment
1 G-LCCOM 255 0-511 *Common Center Adjustment
2 B-LCCOM 255 0-511 *Common Center Adjustment
3 R-LCCOM-Gain 191 0-255
4 G-LCCOM-Gain 191 0-255
5 B-LCCOM-Gain 191 0-255
6 R-LCCOM-Bright 0 0-255
7 G-LCCOM-Bright 0 0-255
8 B-LCCOM-Bright 0 0-255
9 R-LCCOM-Cent 18 0-63
10 G-LCCOM-Cent 18 0-63
11 B-LCCOM-Cent 18 0-63
12 R-ENBX-PW 12 0-127
13 G-ENBX-PW 12 0-127
14 B-ENBX-PW 12 0-127
15 R-DXIN 9 0-255 Link with No.18
16 G-DXIN 9 0-255 Link with No.19
17 B-DXIN 9 0-255 Link with No.20
18 R-CLXIN 9 0-255 Link with No.15
19 G-CLXIN 9 0-255 Link with No.16
20 B-CLXIN 9 0-255 Link with No.17
21 R-ENBX1IN 27 0-255
22 G-ENBX1IN 27 0-255
23 B-ENBX1IN 27 0-255
PLC-XU75
Group101 : Panel Service(6150/1060)
0 R-LCCOM 280 0-511 *Common Center Adjustment
1 G-LCCOM 280 0-511 *Common Center Adjustment
2 B-LCCOM 280 0-511 *Common Center Adjustment
3 R-LCCOM-Gain 191 0-255
4 G-LCCOM-Gain 191 0-255
5 B-LCCOM-Gain 191 0-255
6 R-LCCOM-Bright 0 0-255
7 G-LCCOM-Bright 0 0-255
8 B-LCCOM-Bright 0 0-255
9 R-LCCOM-Cent 18 0-63
10 G-LCCOM-Cent 18 0-63
11 B-LCCOM-Cent 18 0-63
12 R-ENBX-PW 11 0-127
13 G-ENBX-PW 11 0-127
14 B-ENBX-PW 11 0-127
15 R-DXIN 5 0-255 Link with No.18
16 G-DXIN 5 0-255 Link with No.19
17 B-DXIN 5 0-255 Link with No.20
Electrical Adjustments
