Page #80 background imageLoading...
Page #80 background image
Key No. Part No. Description Key No. Part No. Description
KH3-XU7800, KZ3-XU7500
Electrical Parts List
-80-
408 063 7507 ZENER DIODE MM3Z6V2B
D4813 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D5061 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5062 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5601 307 210 5416 DIODE RB551V-30-TE-17
D5611 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
D5612 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
D5622 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5623 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5703 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D5704 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D6801 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6802 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6803 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6831 407 256 6511 LED SML-212YT T86
D6832 307 203 7816 LED SML-210LT T86 M
D6833 307 222 4810 LED SML-521MUW T86
D6841 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6842 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6843 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6844 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D7812 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
D7862 307 254 2716 DIODE CMS16
307 201 2724 DIODE RB051L-40-TE25
MISCELLANEOUS
FB3621 945 086 5368 IMPEDANCE,220 OHM P
FB3622 945 086 5368 IMPEDANCE,220 OHM P
FB3623 945 086 5368 IMPEDANCE,220 OHM P
FB3624 945 086 5368 IMPEDANCE,220 OHM P
FB3626 945 086 5368 IMPEDANCE,220 OHM P
FB3627 945 086 5368 IMPEDANCE,220 OHM P
K10A 952 001 8571 SOCKET,D-SUB 15P
K10B 952 001 8571 SOCKET,D-SUB 15P
K20A 945 076 2735 JACK,RCA-2
952 001 9585 JACK,RCA-2
K20B 945 067 6124 TERMINAL,BOARD
952 001 7932 TERMINAL, BOARD
K30B 945 076 2742 JACK,PHON D3.6
652 002 1808 JACK,PHONE D3.6
K40B 945 078 1613 SOCKET,DIN 8P
952 001 8427 SOCKET,DIN 8P
SC1031 945 076 3503 SURGE-ABSORBER
SC1041 945 076 3503 SURGE-ABSORBER
SC1081 945 076 3503 SURGE-ABSORBER
SC1091 945 076 3503 SURGE-ABSORBER
SC2011 945 076 3503 SURGE-ABSORBER
SC2021 945 076 3503 SURGE-ABSORBER
SC2031 945 076 3503 SURGE-ABSORBER
SC2041 945 076 3503 SURGE-ABSORBER
SC2051 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3011 945 076 3503 SURGE-ABSORBER
SC3051 945 076 3503 SURGE-ABSORBER
SC3061 945 076 3503 SURGE-ABSORBER
SC3081 945 076 3503 SURGE-ABSORBER
SC3082 945 076 3503 SURGE-ABSORBER
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6802 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6810 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
655 001 8489 ASSY,PWB,R/C KH3AC
CAPACITOR
C2901 303 433 1112 CERAMIC 1U K 10V
C2902 303 453 8719 CERAMIC 470P K 50V
303 453 9211 CERAMIC 470P K 50V
303 282 5118 CERAMIC 470P K 50V
C2903 303 378 3110 CERAMIC 47U Z 6.3V
C8833 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R2901 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2903 301 224 8814 MT-GLAZE 100 JA 1/16W
R8831 301 225 8110 MT-GLAZE 10 JA 1/16W
R8832 301 225 8110 MT-GLAZE 10 JA 1/16W
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
