Key No. Part No. Description Key No. Part No. Description
KH3-XU7800, KZ3-XU7500
-81-
Electrical Parts List
655 001 8571 ASSY,PWB,POWER KH3AC
TRANSISTOR
Q611 305 140 3707 TR 2SK2698
Q612 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q613 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q651 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q652 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q662 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 309 523 1413 IC FA5502M
IC641 309 558 4202 IC STR-Z2156A
CAPACITOR
C613 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C614 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C615 303 371 8518 MT-POLYEST 1U K 400V
303 427 2019 MT-POLYEST 1U K 400V
C616 303 371 8518 MT-POLYEST 1U K 400V
303 427 2019 MT-POLYEST 1U K 400V
C617 304 102 7104 ELECT 120U M 420V
304 106 8800 ELECT 120U M 420V
C618 303 371 8617 MT-POLYEST 0.1U K 450V
303 427 1814 MT-POLYEST 0.1U K 450V
C621 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C622 303 323 3615 CERAMIC 0.047U K 50V
304 091 4504 CERAMIC 0.047U K 50V
C623 303 169 2810 CERAMIC 330P J 50V
304 094 8202 CERAMIC 330P J 50V
C624 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C625 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C626 303 394 5815 CERAMIC 4.7U K 16V
C627 303 370 9110 CERAMIC 0.068U K 50V
304 091 5105 CERAMIC 0.068U K 50V
C628 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C629 303 157 3317 CERAMIC 68P J 50V
304 094 9001 CERAMIC 68P J 50V
C631 303 215 1019 CERAMIC 470P J 50V
304 094 8707 CERAMIC 470P J 50V
C632 303 374 4210 CERAMIC 0.33U K 10V
C633 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C641 303 410 7618 ELECT 220U M 35V
C642 303 247 3319 CERAMIC 330P K 2K
304 086 2003 CERAMIC 330P K 2K
C643 303 167 8616 CERAMIC 220P K 2K
304 086 1808 CERAMIC 220P K 2K
C644 303 084 0311 POLYPRO 0.022U J 630V
304 086 9903 POLYPRO 0.022U J 630V
C645 303 265 3216 CERAMIC 1000P J 50V
304 094 6505 CERAMIC 1000P J 50V
C646 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C647 304 091 3408 CERAMIC 0.22U K 50V
C648 303 397 8219 CERAMIC 2.2U K 25V
C649 303 265 3315 CERAMIC 680P J 50V
304 094 9100 CERAMIC 680P J 50V
C651 303 396 9613 CERAMIC 1U K 25V
C652 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C653 303 336 3510 CERAMIC 0.47U K 16V
C654 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C661 303 427 0421 ELECT 2200U M 25V
C662 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C663 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C664 303 422 1304 ELECT 2200U M 10V
C665 303 409 9913 ELECT 470U M 16V
C667 303 336 3510 CERAMIC 0.47U K 16V
C668 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
RESISTOR
R611 302 106 5508 RESISTER 0.075 KB 5W
R612 402 109 2402 OXIDE-MT 68KJA 1W
R613 402 109 2402 OXIDE-MT 68KJA 1W
R614 402 109 2402 OXIDE-MT 68KJA 1W
R615 402 109 2402 OXIDE-MT 68KJA 1W
R616 301 242 3914 MT-GLAZE 240K JA 1/2W
R617 301 242 3914 MT-GLAZE 240K JA 1/2W
R618 301 265 0914 MT-GLAZE 4.7 JA 1/10W
R619 301 152 3219 MT-GLAZE 330 JA 1/10W
R622 301 162 2714 MT-GLAZE 180 JA 1/10W
R623 301 256 2613 MT-GLAZE 2.4K JA 1/10W
R624 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R625 301 036 1218 MT-GLAZE 22 JA 1/8W
R626 301 256 6314 MT-GLAZE 47K JA 1/10W
R627 301 255 9514 MT-GLAZE 220K JA 1/10W
R628 301 256 7519 MT-GLAZE 390 JA 1/10W
R629 301 255 9118 MT-GLAZE 2.2M JA 1/10W
