Sanyo PLC-XU75 Service Manual

Key No. Part No. Description Key No. Part No. Description
KH3-XU7800, KZ3-XU7500
Electrical Parts List
-82-
R631 301 150 5918 MT-GLAZE 10K JA 1/10W
R632 301 256 3818 MT-GLAZE 1.5K JA 1/10W
R633 301 162 3810 MT-GLAZE 470K JA 1/10W
R634 301 255 6810 MT-GLAZE 30K JA 1/10W
R635 301 256 3719 MT-GLAZE 750 JA 1/10W
R636 301 255 6513 MT-GLAZE 100 JA 1/10W
R637 301 259 9015 MT-GLAZE 150K FA 1/2W
R638 301 259 9015 MT-GLAZE 150K FA 1/2W
R639 301 264 6016 MT-GLAZE 2K FA 1/10W
R641 301 305 9211 MT-GLAZE 220K FA 1/2W
R642 301 305 9310 MT-GLAZE 270K FA 1/2W
R643 301 323 4618 MT(LEADFREE 15 JA 3/4W
R644 301 150 6212 MT-GLAZE 1K JA 1/10W
R645 301 257 7419 MT-GLAZE 120 JA 1/3W
R646 301 238 4512 MT-GLAZE 47 JA 1/3W
! R647 324 006 1305 FUSE 250V 2.5A
R651 301 162 2417 MT-GLAZE 1.2K JA 1/10W
R652 301 150 5918 MT-GLAZE 10K JA 1/10W
R653 301 162 4015 MT-GLAZE 560 JA 1/10W
R654 301 256 6611 MT-GLAZE 68K JA 1/10W
R655 301 256 2613 MT-GLAZE 2.4K JA 1/10W
R656 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R663 301 256 0312 MT-GLAZE 820 JA 1/10W
R664 301 150 6212 MT-GLAZE 1K JA 1/10W
R665 301 264 1912 MT-GLAZE 10K FA 1/10W
R666 301 152 3219 MT-GLAZE 330 JA 1/10W
R667 301 265 3915 MT-GLAZE 6.2K FA 1/10W
R668 301 150 6212 MT-GLAZE 1K JA 1/10W
R669 301 150 6212 MT-GLAZE 1K JA 1/10W
R671 301 162 3711 MT-GLAZE 4.7K JA 1/10W
VARIABLE RESISTOR
VR621 952 000 0385 VR,SEMI,1K N
TRANSFORMER
! T651 945 077 6312 TRANS,POWER,PULSE
945 083 6948 TRANS,POWER,PULSE
COIL
! L611 945 086 6853 LINE FILTER
L612 945 077 6565 INDUCTOR,900U
945 084 0273 INDUCTOR,1400U
DIODE
D611 307 191 3903 DIODE FML-G16S
D612 307 164 4015 DIODE RB160L-40-TE25
307 149 6327 DIODE SFPB-54V
D621 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D622 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D623 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D624 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D625 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D641 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D642 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D643 407 256 3213 DIODE CRF03(TE85L)
D661 307 222 9607 DIODE FMB-2306
307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
307 250 2403 DIODE RB225T-60
D662 307 222 9607 DIODE FMB-2306
307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
307 250 2403 DIODE RB225T-60
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D665 309 344 6522 IC UPC1093T-E1
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
FB611 910 244 3975 CORE
FB612 910 244 3975 CORE
FB661 910 244 3975 CORE
FB662 910 244 3975 CORE
FB663 945 041 1978 INDUCTOR,330 OHM
! PC641 307 231 7700 PC TLP421F(D4-BL)
! PC642 307 231 7700 PC TLP421F(D4-BL)
PTH611 308 037 5501 THERMISTOR NTH11D5R0LC
PTH612 408 062 4606 TH PRF18BE471QB1RB
Z6D&CB1 652 002 3536 NONSTANDARD WIRE ASSY
655 001 8564 ASSY,PWB,FILTER KH3AC
CAPACITOR
! C601 304 088 8805 MT-POLYEST 0.22U M 275V
304 104 9601 MT-POLYEST 0.22U K 275V
304 104 9700 MT-POLYEST 0.22U M 275V
304 096 6701 MT-POLYPRO 0.22U M 275V
! C602 304 088 8805 MT-POLYEST 0.22U M 275V
304 104 9601 MT-POLYEST 0.22U K 275V
304 104 9700 MT-POLYEST 0.22U M 275V
304 096 6701 MT-POLYPRO 0.22U M 275V
C603 304 073 4508 CERAMIC 2200P K 250V
C604 304 073 4508 CERAMIC 2200P K 250V
RESISTOR
! R601 302 105 6803 OXIDE-MT 240KJA 1W
VARIABLE RESISTOR
! VA601 308 061 5607 VARISTOR ENE471D-14A-S6
COIL
! L601 945 050 2232 LINE FILTER
LF601 945 059 5357 UNIT,NOISE FILTER
MISCELLANEOUS
! F601 323 021 7804 FUSE 250V 6.3A
PACKING MATERIALS
610 334 8452 CARTON CASE-KH3AC
FOR KH3-XU7800
610 335 6990 CARTON CASE-KZ3AC
FOR KHZ-XU7500
610 335 4859 CUSHION SPACER-KR6AD
610 334 8407 CUSHION L-KH3AC
610 334 8377 CUSHION R-KH3AC
945 068 6864 POLY BAG-0440X0480*NC
