16
Installation
Connecting to Component Video and RGB ( Scart) Equipment
3Note:
:KHQWKH$8',2287LVSOXJJHGLQWKHSURMHFWRUVEXLOWLQVSHDNHULVQRWDYDLODEOH
6HHSDJHIRURUGHULQJRSWLRQDOFDEOHV
Cables used for connection
$XGLR&DEOHV0LQL3OXJVWHUHR
6FDUW9*$&DEOH
&RPSRQHQW&DEOH
&RPSRQHQW9*$&DEOH
(Cables are not supplied with this projector.)
External Audio Equipment
AUDIO IN
Audio cable
(stereo)
Audio cable
(stereo)
Audio Input
Component Video Output
(Y, Pb/Cb, Pr/Cr)
Audio Output
RGB Scart
21-pin Output
Scart-VGA
cable
Component-
VGA cable
AUDIO OUT
(stereo)
Component
cable
COMPUTER IN 1/ S-VIDEO IN / COMPONENT IN
Unplug the power cords of both the projector and external equipment from the AC outlet before connecting
cables.
To Next Page
