Part Names and Functions
D G L8 EJ
Front
Bottom
D Speaker
J Infrared Remote Receiver
8 Focus Lever
E Lens
G Zoom Lever
LLens Cover
CAUTION
Do not turn on a projector with lens cap
attached. High temperature from light beam
may damage lens cap and result in fire
hazard.
(See page 58 for attaching.)
H Air Intake Vent (front and bottom)
< Power Cord Connector
B Exhaust Vent
CAUTION
Hot air is exhausted from the exhaust vent. Do not
put heat-sensitive objects near this side.
 Lamp Cover
 Top Controls and Indicators
 Terminals and Connectors
 Adjustable Foot
 Air Filter
@Kensington Security Slot
This slot is for a Kensington lock used to
deter theft of the projector.
*Kensington is a registered trademark of ACCO
Brands Corporation.
Back

H
B
<
@



H
BB
H
B
B
