9
3. OPERATION OF WIRELESS REMOTE CONTROL UNIT
3.2 Remote Control Unit Functions (Continued)
FAN SPEED selector
button
AUTO :The air conditioner automatically decides the fan speeds.
: Low fan speed.
: Medium fan speed.
: High fan speed.
TEMP button Press to see the set temperature or indoor temperature that are displayed on
the indicator lamp.
: Display the preset temperature.
: Display the indoor ambient temperature (5 seconds)
The ambient temperature will be displayed for 5 seconds,
following which the preset temperature will be displayed.
: Current displaying status will not be changed.
No Icon : Default display of preset temperature.
BLOW button Press to start or stop indoor fan drying indoor components. This function is
applicable to “COOL” & “DRY” mode only. In “AUTO,” “FAN,” and “HEAT”
mode, “BLOW” function is not available and “BLOW” is not displayed.
LIGHT button Press this button to turn ON/OFF indicator light display.
TURBO button Press to quickly cool or heat the room with powerful cool or hot air.
SLEEP button For details, see “SLEEP MODE” (page 12). When you press this button in
the “DRY,” “COOL” or “HEAT” mode, the mark appears in the display and
the remote control unit will automatically adjust the set temperature to save
energy.
CLOCK Button Use this button to set the clock.
How it Works
Press the CLOCK button once if the indicator is not flashing. The
indication alone flashes. Within 5 seconds, press the +/– button. The time
can be set in 1-minute increments. Holding down the button advances the
time rapidly in 10-minute increments. Press the CLOCK button again. The
is displayed, completing the setting of the current time.
SWING Button Sets the air swing direction to change circularly as below:
When the guide louver begins swinging up and down, if swing is turned
off, the air guide louver will stop at the current position. (refer to page
14 for more details)
AUTO
NOTE
OFF
NOTE
OI-180-9-EG
01_SAP-KRV9AEH_EN.fm Page 9 Tuesday, June 8, 2010 3:40 PM
