SPECIFICATIONS
Other Specifications
Operating temperature range 5°C to 40°C (41°F to 104°F)
Operating humidity range 80% or less
Power requirements (TLS-1960P only) 220-240V AC, 50Hz (or DC power: 12 to 24V DC)
Power requirements (TLS-9924P only) 220-240V AC, 50Hz
Power consumption 15 W
Dimensions (W x H x D) 420 mm x 99.5 mm x 306 mm
Weight (TLS-1960P only) approximately 4.2 kg
Weight (TLS-9924P only) approximately 4.0 kg
Connectors (When the “TERMINAL SET” is set to “SET2”)
NOTES:
œ The terminal names and signals are different from the usual setting.
œ Names in brackets apply to terminals on the rear panel.
Clock set input (CONTROL IN) No voltage, make-contact switch input (Low input 100ms or more,
Normally 5 V)
Clock set output (CONTROL OUT) DC 5 V, 5.7kΩ, (Low output)
Eject input (SERIES IN) No voltage, make-contact switch input (Low input 100ms or more,
Normally 5 V)
Eject output (TIMER OUT) DC 5 V, 5.7kΩ, (Low output)
NOTE:
The specifications and external appearance of this unit are subject to change without notice.
RQ4Q/EX (TLS-1960P GB) Wed. May, 08/2002
54
English
