SPECIFICATIONS
General Specifications
Video head system Dual-azimuth 4-head rotating helical scanning system:
Dual azimuth 2-head for record and standard playback
Dual azimuth 4-head for forward picture search, reverse picture search
and still mode
Audio recording In 3-, 12- and 24-hour modes (when using E-180 tape)
Tape speed 23.39 mm /sec (3-hour mode)
Specified video cassette tape VHS 1/2 inch video cassette tape
Recording/playback time (TLS-1960P only) 3, 12, 24, 48, 72, 96, 120, 168, 240, 360, 480, 720 and 960 hours (when
using E-180 tape)
Recording/playback time (TLS-9924P only) 3, 12 and 24 hours (when using E-180 tape)
Fast forward/rewind time approximately 2 minutes (when using E-180 tape)
Television system PAL colour TV system
Video
Recording method Luminance signal: FM recording
Chrominance signal: Down-converted direct recording
Video input 1 V(p-p), BNC, 75 Ω, unbalanced
Video output 1 V(p-p), BNC, 75 Ω, unbalanced
Horizontal resolution Black & white mode 350 line or more
Colour mode 250 line or more
Audio
Input – 8 dBs, RCA pin jack, 27 kΩ, unbalanced
Output – 8 dBs, RCA pin jack, 600 Ω, unbalanced
Microphone input – 60 dBs, 3.5 mm mini jack, 10 kΩ, unbalanced
Connectors
Alarm (1 shot) input No voltage, make-contact switch input (Low input 100ms or more,
Normally 5 V)
Control input Key code (pulse signal) (Normally 5 V)
Series input No voltage, make-contact switch input (Low input 1s or more, Normally 5
V)
Ext timer (alarm reset) input No voltage, make-contact switch input (Low input 100ms or more,
Normally 5 V)
Common 0 V (GND)
Warning output Open collector Max. 500 mA (Active Low 0 V, Normally open)
Control output Key code (pulse signal) (Normally 5 V)
Tape end output Open collector Max. 50 mA (Active Low 0 V, Normally open)
Timer output DC 5 V, 5.7kΩ, (Low output)
Switch output Pulse signal (Normally 5 V)
DC 12-24V “+” input (TLS-1960P only) DC 12 to 24V
DC 12-24V “–” input (TLS-1960P only) DC 0 V
Remote control input 3.5 mm mini jack
