Sanyo VPC-CS1 Service Manual

– 10 –
A
A
C
D
C
B
B
D
12
11
a
c
A
B
9
13
15
10
1
17
16
6
4
5
3
2
4
b
14
2
8
7
32
31
18
26
24
20
22
21
29
28
30
34
35
36
23
25
33
27
39
38
37
40
41
19
B
A
2. DISASSEMBLY
2-1. REMOVAL OF CABINET, TB2 BOARD AND CP2 BOARD
NOTE: Discharge a strobe capacitor with the
discharge jig (VJ8-0188) for electric shock prevention.
When assembling,
tighten the screws order.
a → b → c
When assembling,
tighten the screws order.
A → B
When assembling,
tighten the screws order.
A → B
