Sanyo VPC-CS1 Service Manual

– 11 –
1. Cover USB
2. Two screws 1.7 x 3.5
3. Dec right
4. Two screws 1.7 x 3
5. Shield tape
6. Cover right
7. Dec lens
8. Adhesive dec lens
9. Two screws 1.7 x 4.5
10. Screw 1.7 x 4
11. Two screws 1.7 x 5
12. Cover card
13. Assy, cabi right SV
14. Adhesive card A
15. Adhesive card B
16. Cover battery
17. Cover batt inner
18. Dec front
19. Dec back
20. Screw 1.7 x 3.5
21. Screw 1.7 x 4.5
22. Cabinet left
23. Screw 1.7 x 3
24. Holder battery
25. Spacer HL batt A
26. Spacer HL batt B
27. Spacer CMOS
28. Screw 1.7 x 3
29. Screw 1.7 x 4
30. Heat sink top
31. Earth USB
32. Spacer earth USB
33. Connector (CN602)
34. Screw 1.7 x 3
35. Holder lens top
36. Connector (CN951)
37. TB2 board
38. Connector (CN106)
39. CP2 board
40. Remove the solder.
41. Connector (CN901)
