Dual-Faced / Flag Mounted Clock Mechanical Installation
plastic ring
pole end cap
Flag Mount end cap
10) For Dual-Faced installation: repeat step 9 for attaching a second clock to the other side.
For Flag Mount installation: follow the below two steps.
• Instead of mounting and running two network cables for two clocks, there is a need to run one
network cable to the clock and mount only one clock to the pole.
• The list of items which are included for a dual-faced clock configuration consists of a Flag
Mount End Cap, which is not in use for a dual clock mounting configuration, but is needed for a Flag
Mounted installation. After completion of the pole and clock installation, there is a need to install the
Flag Mount End Cap by following the below additional steps:
1) Remove the mounting pole end cap and the plastic ring from one of the holes.
2) Attach the flag-mount end cap to the pole. Confirm that the covering flap is attached to the side
where the plastic ring was removed.
