Identify Your Clock
The digital clocks are offered at either 3100, 3200, or 3300 Series number. The higher the series
number indicates that the clock has higher feature set and capabilities.
3100 Series clock electric board layout:
3200 Series clock electric board layout:
3300 Series clock electric board layout:
Additional Ports
Relay Output Ports
Interface Port for Elapsed
Timer Control Panel or
Temperature Sensor Port
Interface Port for Elapsed
Timer Control Panel or
Temperature Sensor Port
PoE Connector
PoE Connector
PoE Connector
