You will need the following items to set up an IP-based synchronized clock network:
• This manual
• A Local Area Network (LAN) that either has access to at least one of the following:
• An in-house NTP server
• The Internet
• A local firewall that is open on Ports 80 (TCP), 123 (UDP), and 1777 (UDP)
• Port 123 is to allow the clock to get time data from NTP Time Server(s)
• Port 80 is to allow access to the clock’s built-in web interface (HTTP)
• Port 1777 is to allow the NET-MON-SOFT to identify our clocks that are on the
network and present them on the network monitoring software
• At least one laptop or desktop computer with access to this LAN and a web browser
• A copy of the Monitor.exe program
• Security access to all of the above items
• A crossover cable and PoE injector or for programming the clocks. (Optional - A clock can also
be programmed over a network.)
• We also recommend keeping a record of the clock serial numbers, locations, and IP addresses by
creating a table like the one shown below:
Before Installation - System/Network Requirements
SERIAL #LINE # IP ADDRESS MAC ADDRESSCLOCK NAME / LOCATION
1
2
3
4
5
6
7
8
9
10
