Sartorius Combics 3 CAIS3 - COM1 XBPI RS-232 Configuration; XBPI RS-232 Settings for COM1

61
Device Parameters
COM 1
Data communications
o SBI
Line format
For raw data (16 characters)
o For other apps. (22 characters)
Sign format
Do not output + sign
o Output + sign
Factory setting
Yes
o No
XBPI RS-232
SMA
Baud rate
150 baud
300 baud
600 baud
o 1200 baud
2400 baud
4800 baud
9600 baud
19200 baud
Parity
Space
1
)
Odd
Even
o None
2
)
Number of stop bits
o 1 stop bit
2 stop bits
Handshake mode
Software handshake
o Hardware 1-char
Number of data bits
o 8 bits
1
) Not with 8 data bits
2
) Not with 7 data bits
Operating Design
