Sartorius Combics 3 CAIS3 - COM2 and UniCOM Interface Parameters; COM2 Interface Configuration Options; UniCOM Interface Configuration Options

63
Device Parameters
COM 2 similar to COM 1
UNICOM (optional interface)
o Off
WP 3
o RS-232
SBI standard (9600 baud)
SBI verifiable (9600 baud)
o IS-232
1
)
ADC-232
1
)
RS-485
o IS-485
1
)
ADC-485
1
)
Data communications
o SBI similar to COM 1
xBPI-232 similar to COM 1
xBPI-485 address 0 to 31 can be selected
SMA similar to COM 1
Profibus address: 0 to 126 can be selected,
factory setting: 126
Ethernet
Printer 1
1
) Similar to COM 1
Printer 2
1
) Similar to COM 1
Analog output
Analog output: value
o Net value
Gross value
Analog Out: Error Signal
o High level (20 mA)
Low level (0/4 mA).
When menu is open or during
calibration
(0/4 mA) on this interface.
Analog output: mode
o Zero to maximum capacity
Minimum/Maximum values
Analog Out: Data Output Min./Max.
o Min. (0/4 mA) input in kg
Max. (20 mA) input in kg
1
) Not with 8 data bits
Operating Design
