22 Operating Instructions Cubis

MCA

Operating Design

4.2 Operating Elements in Task Management

Fig. 2: Operating elements in Task Management (example)

Pos. Name Description

1 Navigation and function bar − Enables navigation and searching in menus and lists.

− Enables the addition of tasks.

− Opens the QAPP Center.

− Displays the name of the menu.

2 Available tasks − Displays all available tasks.

− Opens a summary of the properties for the displayed task.
