76 Operating Instructions Cubis
®
MCA
System Settings
7.7.16 Parameters in the “Connections / Connected Devices / Motion Sensor” Menu
(onlyforconnected motion sensors)
Parameter Setting Values Explanation
Number
ofgestures
2 gestures (left, right)* Activates the control of functions with 2 gestures.
Gestures:left,right.
4 gestures (left, right,
up, down)
Activates the control of functions with 4gestures.
Gestures:left,right, down, up.
Any gesture Activates the control of functions with any gesture.
Left gesture
Right gesture
Up gesture
Down gesture
No action Disables the functions of the motion sensor.
Start / cancel taring The gesture starts a taring process or cancels a taring process.
Start / cancel zeroing The gesture starts the zeroing process or cancels the
zeroingprocess.
Zeroing / taring Starts or ends the “Zeroing/taring” function.
Ionizer key If the device is equipped with an ionizer: The gesture starts
orends the ionizer function.
Takeover key Uses the gesture to start an application or adopts displayed
weight values.
Left key, draft shield If the device is equipped with a motorized draft shield:
The gesture executes the left palm key function.
Right key, draft shield If the device is equipped with a motorized draft shield:
The gesture executes the right palm key function.
Open left (DI / DA) If the device is equipped with a motorized draft shield:
The gesture opens the left side panel.
Open right (DI / DA) If the device is equipped with a motorized draft shield:
The gesture opens the right side panel.
Open top (DI / DA) If the device is equipped with a motorized draft shield:
The gesture opens the upper panel.
Close all (DI / DA) If the device is equipped with a motorized draft shield:
The gesture closes all draft shields.
* Factory setting
