Operating Instructions PMA 35001-X 27
Specifications
Specifications
Model PMA 35001-X
Weighing Capacity g 35000
Readability g 0.1
Tare range (subtractive) g -35000
Linearity g ≤±0,2
Stability range (configurable in menu) Digit 0.25 to 4
Humidity class F non-condensing
Permissible ambient operating temperature range °C 0 to +40
IP protection IP 43, in accordance with EN60529/IEC60529
Load plate dimensions mm 350 + 240
Scale housing (WxDxH) mm 350 + 243 + 132,5
Net weight, approx. kg 11.4
External calibration weight kg 10 (accuracy class F2 or better)
Interface RS232
Format 7-bit ASCII, 1 start bit, 1 or 2 stop bits
Parity Even, odd, none
Transmission rates 1200 to 38,400 bps
Handshake Software or hardware
Power consumption VA Average: 8, max. 16
Mains Connection V 100 – 240 V ~
Voltage frequency Hz 50 – 60
Device ID (explosion protection) II 2G Ex ia IIC T4 Gb
DEKRA 12ATEX0180 X The terminal/control panel is
suitable for use in potentially explosive areas in
accordance with Directive 94/9/EC
Zone1 (devices in category 2)
Ambient conditions
Environment For indoor use only
Ambient temperature: Storage and shipping -10 °C … +60 °C
Ambient temperature: Operation 0 °C … +40 °C
Highest relative humidity: 80 % for temperatures up to 31 °C, decreasing linearly up to
50 % relative humidity for 40 °C
Safety of electrical equipment
as per EN 61010-1:2010
Safety requirements for electrical equipment for
measurement, control, and laboratory use — Part 1:
Generalrequirements
Electromagnetic compatibility
Defined immunity to interference:
Limitation of emissions:
as per EN 61326-1:2006
Electrical equipment for measurement, control, and labora-
tory use — EMC requirements — Part 1: General requirements
Industrial areas
Class B: Suitable for use in residential areas and areas that
are directly connected to a low voltage network
