Sartorius Quintix User Manual

25
Using the Balance
User Manual Secura
®
, Quintix
®
, Practum
®
5.3.3 Enter Figures on the Keypad
g
Min
123
456
789
+/- 0.
C
+
0000000
Numerical values can be entered for many applications or system settings (such as
a minimum value for the Checkweighing application). A keypad appears on the
display, which can be used for this purpose.
t To enter numbers or values, touch the corresponding numbers in order.
Theentered numbers appear at the top of the display.
t To correct the most recent number, selectk.
The number is deleted. Then enter the correct number.
t To delete the entire value, select C.
t To confirm the entry, selectl.
5.3.4 Text and Character Input (Secura
®
only)
A keyboard will appear whenever you have to enter text or characters. The cursor is
located in the line above the keyboard.
t Select the desired character simply by touching them.
y The entered text will appear in the input line.
t Press the shift button to change between uppercase and lowercase letters.
t Press the 123 key to switch from letters to numbers.
t Press the ABC key to switch from numbers to letters.
t The backspace key is used to delete the character to the right.
t The l key ends the process and saves the characters entered.

Sartorius Quintix Specifications

General

Display	Backlit LCD
Response Time	1.5 s
Operating Temperature	+10°C to +30°C
Readability	0.1 mg to 1 g
Calibration	Internal/External
Connectivity	RS-232, USB
Repeatability	0.1 mg
Linearity	±0.2 mg
Operating Humidity	15% to 80% non-condensing
Power Supply	100 – 240 V, 50/60 Hz
Pan Size	Varies by model, typically 90 mm diameter (round) or 190 x 204 mm (rectangular)
