43
Service Manual Signum
Replacing Components
Replacing the System PCB
Important note:
Please refer to page 37, „Opening a Scale Featuring Strain Gauge
Technology
– Strain gauge scale with system PCB
– When you replace the system PCB, make sure that all cables have been
reconnected.
Important note:
See page 38, „Opening a Scale Featuring Electromagnetic Force
Compensation“
– Electromagnetic force compensation scale with system PCB
– When you replace the system PCB, make sure that all cables have been
reconnected.
