33
Maintenance
Changing the Paper Roll
To operate your data printer, the paper rolls must have the
following specifications:
(see “Accessories”):
– Standard paper roll
– Wood-free paper, 60 g
– Width: 57.5 ± 0.5 mm
– Diameter: 65 mm max.
– Core diameter: 8 mm min.
§ To open the paper roll compartment, lift the cover
§ Pull out the roll holders from both sides of the roll core as
shown on the left
§ Remove the old roll core
$ Place a new paper roll on a flat surface
$ The beginning of the paper must be on the bottom and
facing you
§ Use your thumb and index finger of one hand to hold the
paper roll vertically above the paper roll compartment
§ Using your other hand, thread the paper through the slot
underneath the ink ribbon
§ To transport the paper through the ink ribbon cassette,
press the key several times or hold it down
> The paper will be threaded into, then out of the ink ribbon
cassette
To Next Page
