Multilift Installation Guide Part No. 000643, 26-m02-2013
Page 2
Standard notations
The following notations may be used throughout this guide to emphasize important safety information,
mechanical concerns, and other important information. Savaria Corporation recommends that you review and
follow all of these messages.
Danger messages indicate an imminently hazardous situation, which, if not avoided, results in death or seri-
ous injury. All danger messages feature a standard ISO safety alert symbol followed by the signal word
DANGER in capitalized black lettering on a red background.
Warning messages indicate a potentially hazardous situation, which, if not avoided, could result in death
or serious injury. All warning messages feature a standard ISO safety alert symbol followed by the signal
word WARNING in capitalized black lettering on a dark yellow background.
Caution messages indicate a potentially hazardous situation, which, if not avoided, could result in death or
serious injury. All caution messages feature a standard ISO safety alert symbol followed by the signal word
CAUTION in capitalized black lettering on a yellow background.
Caution messages that do not include the ISO safety alert symbol indicate a potentially hazardous situation
for the machine only, which, if not avoided, could result in damage to the machine. All caution messages
include the signal word CAUTION in capitalized black lettering on a yellow background.
Note messages provide information, such as reminders, general information about a previous statement,
or additional guidelines that do not fit into the flow of the preceding text. All note messages include the
signal word NOTE in capitalized white lettering on a blue background.
DANGER
WARNING
CAUTION
CAUTION
NOTE
Hazards and warnings
ELECTRICAL SHOCK HAZARD
Do not connect or disconnect wiring while the power is
on. Before servicing, disconnect all power to the
equipment.
WARNING
SUDDEN MOVEMENT HAZARD
System may start unexpectedly upon application of
power. Unpredictable equipment operation may result in
death or serious injury.
ELECTRICAL SHOCK HAZARD
Savaria Corporation is not responsible for any
modifications of the product made by the user.
Do not allow unqualified personnel to use equipment.
Failure to comply could result in death or serious injury.
Maintenance, inspection, and replacement of parts must
be performed only by authorized personnel familiar with
installation, adjustment, and maintenance.
Do not remove covers or touch circuit boards while the
power is on.
WARNING
FIRE HAZARD
Do not use an improper voltage source.
Verify that the rated voltage matches the voltage of the
incoming power supply before applying power.
Job site tools
The following list provides the recommended tools and
materials to use during installation:
•Electric drill
• Metal and concrete drill bits
• Hammer drill for concrete fasteners
•Electric grinder
• Allen wrenches (inch sizes)
• Screwdrivers (including Robertson #1, 2, 3)
• Socket and wrench set (inch sizes)
• Level
• Vise-grip pliers
•Cutting pliers
• Multimeter
•Box cutter/knife
• Scissors
• 10'' medium cut file (for filing joints) - optional
• Wall anchors
• 25' tape measure
•Carpenter’s level and square
• Plumb bob and line
•Chalk line
• Metal and wood stud finder
• Multimeter
• Safety items (as required): hard hats, safety glasses, steel
toe shoes, heavy gloves, etc.
• Hand dolly
