Part No. 000643, 26-m02-2013 Multilift Installation Guide
List of installation steps
WARNING
Follow the steps provided to ensure your safety during
installation. Failure to follow instructions renders the
Limited Warranty null and void. In addition, any party
installing the product who deviates from the installation
instructions agrees to indemnify, save, and hold harmless
the manufacturer from any and all loss, liability, or
damage that may occur as a result of the deviation.
The following table lists the installation steps.
Steps Page
Double-check site specifics 5
Unpack and verify shipment 5
Verify cab type (handing) 6
Position lift 6
Power up lift for installation 8
Anchor lift to pad/floor 9
Adjust limit switches (as required) 10
Install landing gate or door 11
Install locks and operators (as required) 13
Install hall calls (as required) 13
Wind gate spring hinges 14
Adjust gate closer (as required) 15
Permanently install battery (batteries) 16
Verify operation 16
Reverse power cord (if required) 17
Reverse automatic access ramp (if required) 18
Disassemble/reassemble the acme screw (if
required)
19
Before leaving job site 23
Maintenance 24
Disclaimer
Savaria (Savaria Concord Lifts, Inc.) disclaims liability for
any personal injury or property damage resulting from the
operation of a product that has been modified from the
original Savaria design. No person or company is authorized
to change the design of this product without written
authorization by Savaria.
Revision history of this guide
October 1, 2010 – Initial release of new format
October 19, 2011
• Updated Step 5 on page 8 so specify Group 22F
battery
• Updated Step 7 on page 10 to indicate that limit
switch configuration in an example
January 3, 2012
• Added Pro-door installation drawings to Appendix A
June 14, 2012
• Revised landing gate harness drawing in Appendix A
(changed Euchner/Sick Lock to WR500 Lock)
July 31, 2012
• Revised landing gate harness drawing in Appendix A
(notes added at bottom of GAL and WR500 boxes)
November 16, 2012
• Added disclaimer (above)
• Revised Step 5 on page 8
• Added new Step 13 on page 16 to permanently intall
batteries
• Revised Maintenance section on page 24
February 26, 2013
• Added a Note and photo on page 5 as a reminder to
remove the shipping straps; added same reminder to
Note on page 6
