Chapter 2 Installation Communications Connections
EM13x Series SMART MULTIFUNCTION METER 55
The GSM/GPRS SIM must not have any incoming voice call.
The customer must require from the Service Provider for DATA
services only
The GPRS modem module can be equipped with two different
antennas: internal Antenna for installation into plastic closet or
no-metallic environment. For metallic installation use external
antenna
See Setting Up GPRS in Chapter 5 for information on configuring GPRS
communications in your meter.
Connecting an RF module
Figure 2-25 COM2 RF module Connection
The RF modem module can be equipped with two different
antennas: internal Antenna for installation into plastic closet or
no-metallic environment. For metallic installation use external
antenna
