Chapter 3 Using Front Display Data Displays
64 EM13x Series SMART MULTIFUNCTION METER
MAX. DMD
V3 0 V
Max. DMD Phase 3 voltage data
Instrumentation Measurement
Instrumentation Measurements represent general instrumentation data
you can use while installation and inspecting the meter. Use phase
angles displays to check the order of phases when connecting wires to
the meter terminals.
DISPLAY
Description
V1 0 V
V2 0 V
V1 and V2 Phase-to-neutral voltages.
Only displayed in 4-wire configurations
with a neutral.
V3 0 V
V2 Phase-to-neutral voltage
V12 0 V
V23 0 V
Phase-to-Phase voltages.
V31 0 V
Phase-to-Phase voltages.
I1 0 A
I2 0 A
Phase currents.
I3 0 A
In 0 A
Phase currents, neutral current is
calculated.
P 0 kW
Q 0 kvar
Total powers.
S 0 kVA
PF 0
Total apparent power and total power
factor
L1 P 0 kW
L1 Q 0 kvar
Phase 1 active and reactive power
