Satec Expertmeter Series Quick Start Guide

EM132-133 QUICK START GUIDE
BG0504 REV.A2
10
Input and Output Ratings
DIRECT INPUT - Nominal: 690V line-to-line voltage, 828V maximum;
400V line-to-neutral, 480V maximum - Burden: <0.5 VA. INPUT USING PT
- Burden: <0.15 VA
57/98-400/690 VAC
3 voltage inputs
4 x Maximum wire section: 2.5 mm² (12 AWG)
Voltage input terminals
INPUT VIA CT with 5A secondary output - Burden: <0.2VA, Overload
withstands: 20A RMS continuous, 300A RMS for 0.5 second.
/5A(10A)
3 current nputs
(Galvanic isolation)
INPUT VIA CT with 1A secondary output - Burden: <0.05VA, Overload
withstands: 3A RMS continuous, 80A RMS for 0.5 second.
/1A(2A)
INPUT VIA CT with 50A direct connection - Burden: < 0.05VA, Overload
withstands: 120A RMS continuous, 2000A RMS for 0.5 second.
50A(100A)
INPUT VIA CT with 40mA secondary output, using external CT – Split
Core CT or Solid Core CT – primary 100-1200A maximum rating
40mA:(optional)
3 x Maximum wire section: 16 mm²
Current input terminals
Optically isolated, max. speed 115.2Kb/s
EIA RS-485 standard
Communication port
COM1
3 x Maximum wire section: 2.5 mm²
COM1 terminals
Infra Red, max. speed 38.4Kb/s
IR COM port
Communication port
COM3
50/60 Hz - 9VA
40-300V AC/DC
(standard)
Power Supply
(Galvanically
isolated)
3 x Maximum wire section: 2.5 mm²
Power Supply input
terminals
Dry contact, internally wetted @ 5VDC
DIGITAL INPUT x 2
optically isolated inputs
MODULE 2DI/DO
0.15A/250 VAC - 400 VDC, 1 contact (SPST Form A)
DIGITAL OUTPUT x 1
5 x Maximum wire section: 2.5 mm²
2DI/DO terminals
Dry contact, internally wetted @ 24VDC
DIGITAL INPUT x 2
optically isolated inputs
MODULE 4DI/2DO
(Optional)
5A/250 VAC; 5A/30 VDC, 1 contact (SPST Form A)
EMR
DIGITAL
OUTPUT x 2
0.15A/250 VAC - 400 VDC, 1 contact (SPST Form A)
SSR
9 x Maximum wire section: 2.5 mm²
4DI/2DO terminals
1 mA, maximum load 5 k (100% overload)
ANALOG OUT x 4
optically isolated
outputs
(4 different options)
MODULE 4 AO
(Optional)
0-20 mA, maximum load 510 
4-20 mA, maximum load 510 
0-1 mA, maximum load 5 k  (100% overload)
5 x Maximum wire section: 2.5 mm²
4 AO terminals
10/100 Base T, auto adaptation speed, Max. speed 100Mb/s
Ethernet
Communication port
COM2 (Optional)
Shielded RJ45 cable
ETH connector
Max. speed 12 Mb/s
Profibus
Communication port
COM2 (Optional)
5 x Maximum wire section: 2.5 mm2 (12 AWG) or using terminal to DB9
converter: P/N AC0153 REV.A2
Profibus terminals
Optically isolated, max. speed 115.2Kb/s – to be connected to GPRS
modem if ordered
EIA RS-232-422/485
standard
Communication port
COM2 (Optional)
5 x Maximum wire section: 2.5 mm²
And DB9 connector
COM2 terminals
