Satec Expertmeter Series Quick Start Guide

EM132-133 QUICK START GUIDE
BG0504 REV.A2
9
Basic Menu
Code
Parameter
Options
Description
ConF
Wiring mode
3OP2
3-wire open delta using 2 CTs
4Ln3
4-wire Wye using 3 PTs (default)
3dir2
3-wire direct connection using 2 CTs
4LL3
4-wire Wye using 3 PTs
3OP3
3-wire open delta using 3 CTs
3Ln3
4-wire Wye using 2 PTs
3LL3
4-wire Wye using 2 PTs
3bLn3
3-wire Broken delta using 2 PTs, 3 CTs
3bLL3
3-wire Broken delta using 2 PTs, 3 CTs
Pt Ratio
PT ratio
1.0 - 6,500.0
The potential transformer ratio
Pt Factor
Ct
CT primary current
1-50,000A
(5*)
The primary rating of the current transformer
PowDmdPer
Power demand period
1, 2, 5, 10, 15*, 20,
30, 60, E
The length of the period for power demand calculations, in
minutes. E = external synchronization
Num.Per.
Number of power
demand periods
1-15
(1*)
The number of demand periods to be averaged for sliding window
demands
1 = block interval demand calculation
ADmdPer.
Ampere/Volt demand
period
0-1800
(900*)
The length of the period for volt/ampere demand calculations, in
seconds. 0 = measuring peak current
Frequency
Nominal frequency
25, 50, 60, 400 (Hz)
The nominal power utility frequency
MaxDmdLd
- Default setup
Communication Port Menu
COM1 setting
Code
Parameter
Options
Description
Protocol
Communications protocol
ASCII, rtu, dnP3
ASCII, Modbus RTU (default) or DNP3.0
protocol
Interface
Interface standard
485
RS-485 interface (default)
Address
Address
ASCII: 0 (default) - 99, Modbus: 1 (default) -247, DNP3.0: 0 (default) -255
Baud Rate
Baud rate
110, 300, 600, 1200, 2400, 4800, 9600 (default), up to 115,200 bps
Data/Party
Data format
7E, 8E (7/8 bits, even parity), 8n (default) (8 bits, no parity)
Snd.Delay
