Using the MOBILEKPD2 PRO application you can control the KNX system, provided
that the INT-KNX module is connected to the control panel.
5.3.2 Defining the macro commands
1. Click on the "Definition" tab.
2. Click on the "New macro" button. A new macro command will appear in the list.
3. Enter a name for the new macro command.
4. If the macro command is to be run without entering the code by the user, enter the code
with a suitable authority level.
5. If running the macro command is to be each time preceded by user authorization, enable
the A
UTHORIZATION REQUIRED option.
6. If the macro command is not to be available, when any of the partitions operated by the
keypad is armed, enable the D
ISABLED IF ARMED option.
7. If the macro command is to be run instantly on touching the macro key, enable the
and will appear in the list of commands assigned
can still make a correction to
he
ge" button.
10 to add next commands.
which is
to be added.
5.3.3
application is to run the sam
e macro commands which have
A
UTOEXECUTE option (in such a case, only this one macro command is to be assigned to
the group).
8. Select from the list one of the commands to be executed by the new macro command.
9. Select the partitions (arming / disarming, alarm clearing), zones (inhibiting / unbypassing)
or outputs (activating / deactivating) controlled by the command. Click twice to
select/deselect the required field.
10. Click on the "Add" button. A new comm
to the macro command. After clicking on the command you
es / outputs controlled by the command. After making tthe list of partitions / zon
changes, click on the "Chan
11. If necessary, repeat the steps 8-
12. Click on the "Groups" tab.
13. Click on the group to be edited.
14. Enter the group name.
15. Click on the "Add macro" button. Select in the pop-up menu the macro command
Preparing the macro command file for MOBILEKPD2 PRO application
If the M
OBILEKPD2 PRO
been defined for the INT-KSG ma keypad, the steps described below can be done in
the "Macro commands" tab for the INT-KSG keypad.
1. Click on the "Groups" tab.
2. Click on the "Export to file" button.
3. In the window that will be displayed, enter the name of file, and then click on the "Save"
button. If the file is to be saved in another location than the default one, indicate the
suitable folder before you click on the "Save" button.
4. A window will open, where you should enter the file encry
alphanumeric characters), and then click on the "OK" button. The file
ption code (up to 24
encryption code will
be required when loading the macro commands by the MOBILEKPD2 PRO application.
5. A window will open with information that the file has been saved.

Satel ETHM-1 Specifications

Power

supply voltage	12 V DC ±15%
standby current consumption	120 mA
maximum current consumption	120 mA

Operating Environment

environmental class according to EN50130-5	II
operating temperature range	-10 to +55 °C
maximum humidity	93±3%

Weight and Dimensions

dimensions	68 x 140 mm
weight	64 g
