SATEMA X-Chain - Machine Controls__Maskinens Kontroller

Manual code - MI400A00115 Revision Level 00 - 05/08/2020
11



1) 230V16AShukoPowerinlet
2) 230V16AShukoPoweroutlet
3) Earthingterminal
4) Floodlightsswitch
5) Lightsensor
6) Astronomicaltimer
7) Operationmodeselectorswitch
1. Nettinntak230V16AShuko
2. El‐uttak230V16AShuko
3. Jordkabelklemme
4. Lyskasterbryter
5. Lyssensor
6. Astronomisktimer
7. Bryterforvalgavdriftsmodus


ON
OFF
LIGHT SENSOR
MANUAL MODE
OFF
TIMER
LAMP
LIGHT
SENSOR
TIMER
ASTRONOMICAL
POWER INLET
230V OUTLET
MACHINE

CONTROLS
__
MASKINENS

KONTROLLER

TECHNICALSPECIFICATIONS__TEKNISKEDATA
1
2
3
5
6
7
4
